Vertiv Liebert GXT5-2000LVRT2UXLTAA GXT5 TAA UPS - 2000VA/1800W 120V Online 2U Rack/Tower UPS - Double Conversion | 0.9 Output Power Factor | Energy Star 2.0 certified with NEMA L5-20P plug,
- Status Indicators Color LCD
- Modem (RJ-11) No
- Serial Port Yes
- EPO Port Yes
- USB (HID Compliant) Port Yes
- Maximum Operating Temperature 104°F (40°C)
- Maximum Operating Elevation 9842.52 ft
- Maximum Storage Elevation 49212.60 ft
- Environmental Sensors: Leak Detection Sensor, Temperature Sensor, Humidity Sensor
- Application/Usage IT Equipment
- Mission Critical Equipment
- Emergency Power OFF Yes
- Plug/Connector Type NEMA L5-20P
- Cord Length 10 ft
- Phase Single Phase
- Receptacle Type NEMA 5-15/20R, NEMA L5-20R
- Transfer Time 0 ns
- Receptacle Detail 1 x NEMA L5-20R, 6 x NEMA 5-15/20R
- Circuit Breaker Yes
- Input Voltage 120 V AC
- Output Voltage 120 V AC
- Input Current 16 A
- Waveform Type Pure Sine Wave
- Output Current 16.70 A
- Input Voltage Range 60 V AC - 150 V AC
- Input Frequency 70 Hz
- Load Capacity (VA) 2000 VA
- Load Capacity (Watt) 1800 W
- User Selectable Output
- Typical 120V User Selectable Output: 110/115/120VAC (user-configurable)
- Battery Life 5 Year
- Battery Chemistry Lead Acid
- Hot Swappable Yes
- Battery Size 12V
- Hot Pluggable Yes
- Number of Batteries 3
- Backup/Run Time (Half Load) 9 Minute
- Backup/Run Time (Full Load) 3 Minute
- Battery Characteristics Valve-regulated, Non-spillable
- Typical Battery Recharge Time 3 Hour
- Number of External Battery Cabinets 1
- Backup/Run Time With External Battery Cabinet (Full Load) 17 Minute
- Backup/Run Time With External Battery Cabinet (Half Load) 42 Minute
- Environmentally Friendly Yes
- TAA Compliant Yes
- Energy Star Yes
+
+
Overview
Specs
Reviews
See all Q & A
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 1 year
- Read full details
Return Policies
- Contact Manufacturer for Assistance
- This item is covered by Newegg.com's Manufacturer Warranty Only Return Policy.
- Read full return policy for details.
Manufacturer Contact Info
LOADING...
The Vertiv Liebert GXT5-2000LVRT2UXLTAA is a 2U rack/tower online double-conversion UPS for IT and mission-critical equipment needing 120V power protection up to 2000VA/1800W, with a zero-transfer-time design, pure sine-wave output, and TAA compliance.
Recommended For
- Small business IT teams protecting servers, storage, and network equipment in a rack or equipment room that needs continuous power conditioning and battery backup.
- IT administrators who need a TAA-compliant UPS for eligible government or other procurement programs and can provide the required 120V L5-20P power connection.
- Operators of equipment sensitive to power disturbances who want online double-conversion protection rather than a basic standby UPS.
- Rack or equipment-room operators who want a 2U rack/tower UPS with hot-swappable lead-acid batteries and the option to add an external battery cabinet for longer runtime.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Backup power for IT and mission-critical equipment within a 2000VA/1800W capacity |
| Power Capacity | 2000VA / 1800W |
| Electrical Input And Output | 120V input with a 60–150V input range; configurable 110/115/120/125VAC output with ±3% tolerance; NEMA L5-20P input connection |
| Outlet Configuration | 7 outlets: 1 × NEMA L5-20R and 6 × NEMA 5-20R |
| Battery System | Lead-acid battery with a stated average life of 7 years and a 5-hour recharge time |
| Installation And Physical Specifications | Rack form factor; 3.4 × 16.9 × 18.5 inches; 47.5 lb; black |
| Model Identifiers | Vertiv Liebert GXT5-2000LVRT2UXLTAA |
