Vertiv Switched rPDU with Outlet Level Switching & Input Monitoring, 20A, 120V, 24-Port, 0U Vertical Model VP5N20A4
- REMOTE OVERLOAD PREVENTION: The Vertiv PowerIT Switched Rack PDU allows users to remotely turn off receptacles to avoid accidental overloads.
- REMOTE REBOOT CAPABILITY: It enables outlet-level power cycling to reboot unresponsive IT equipment or extend runtime of critical systems during power outages.
- VERTIV POWERIT NEXT-GENERATION IMD: It has an internal orientation sensor that intelligently adjusts the screen based on horizontal or vertical installation.
- SAFEGUARDED DATA: It offers enhanced security with Secure Boot that utilizes a hardware-based trust anchor, and a redundant power-sharing port that connects two IMDs in the rack and provides backup power.
- TESTED & BACKED FOR RELIABILITY: Each unit is individually tested for functionality and compliance (UL, RoHS, TAA)
+
+
Learn more about the Vertiv VP5N20A4
| Brand | Vertiv |
|---|---|
| Model | VP5N20A4 |
| Part Number | VP5N20A4 |
| Type | Switched |
|---|---|
| Rack Size | 0U |
| Style | Vertical |
| Certifications | UL & c-UL Listed 62368-1 |
| ROHS | RoHS Compliant |
| Input Voltage | 100-120V |
|---|---|
| Input Frequency | 50/60Hz |
| Maximum Input Current | 20A |
| Cord Length | 10ft / 3m |
| Output Voltage | 120V |
|---|---|
| Output Frequency | 50/60Hz |
| Output Connector(s) | 24 x |
| Overload Protection | None |
| Operating Environment | Maximum operating temperature 60C / 140F |
|---|
| Features | Dual 10/100/1000Mbps Ethernet |
|---|
| Dimensions | 66.25 inches x 2.6 inches x 1.02 inches |
|---|
| First Listed on Newegg | September 21, 2026 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 5 years
- Limited Warranty period (labor): 5 years
- Read full details
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.com's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
LOADING...
The Vertiv VP5N20A4 is a 0U vertical, 20A/120V switched rack PDU with 24 outlets, input power monitoring, and remote outlet control, suited to data centers and server rooms that need to manage and reboot connected IT equipment over the network.
Recommended For
- IT teams managing a 0U rack in a server room or data closet who need to remotely reboot individual connected devices and check rack-level input power.
- Administrators supporting remote or lightly staffed sites who want to power-cycle an unresponsive rack device without sending someone to the rack.
- Rack operators who want to monitor total PDU input power and remotely switch outlets, but do not need separate energy readings for each outlet.
- Facilities standardizing on a compatible 120V, 20A rack-power setup with room for a long vertical PDU and 24 NEMA 5-20R outlets.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | 0U vertical rack installations requiring switched power distribution across 24 connections for IT equipment |
| Power Input | 100–120V input at 50/60Hz, with a maximum input current of 20A |
| Power Output | 120V output at 50/60Hz, with 24 output connectors and 1900W listed |
| Power Protection | No overload protection |
| Networking | Dual 10/100/1000Mbps Ethernet |
| Rack Installation And Dimensions | 0U vertical format; 66.25 × 2.6 × 1.02 inches, with a 10ft / 3m cord |
| Operating Environment | Maximum operating temperature of 60°C / 140°F |
| Compliance | UL and c-UL Listed 62368-1; RoHS compliant |
| Weight | 21.2 pounds |
| Model Identifiers | Vertiv model and part number VP5N20A4 |
