Vertiv Switched 1U PDU with Remote Outlet Switching & Power Monitoring, 30A, 120V, 12-Port NEMA Model VP5N31A0
- REMOTE OVERLOAD PREVENTION: The Vertiv PowerIT Switched Rack PDU allows users to remotely turn off receptacles to avoid accidental overloads.
- REMOTE REBOOT CAPABILITY: It enables outlet-level power cycling to reboot unresponsive IT equipment or extend runtime of critical systems during power outages.
- VERTIV POWERIT NEXT-GENERATION IMD: It has an internal orientation sensor that intelligently adjusts the screen based on horizontal or vertical installation.
- SAFEGUARDED DATA: It offers enhanced security with Secure Boot that utilizes a hardware-based trust anchor, and a redundant power-sharing port that connects two IMDs in the rack and provides backup power.
- TESTED & BACKED FOR RELIABILITY: Each unit is individually tested for functionality and compliance (UL, RoHS, TAA)
+
+
Learn more about the Vertiv VP5N31A0
| Brand | Vertiv |
|---|---|
| Model | VP5N31A0 |
| Part Number | VP5N31A0 |
| Type | Switched |
|---|---|
| Rack Size | 1U |
| Style | Horizontal |
| ROHS | RoHS Compliant |
| Input Voltage | 100-120V |
|---|---|
| Input Frequency | 50/60Hz |
| Maximum Input Current | 30A |
| Cord Length | 10ft / 3m |
| Output Voltage | 120V |
|---|---|
| Output Frequency | 50/60Hz |
| Overload Protection | (2) 20A Single Pole Magnetic Breakers (10kAIC Rated) |
| Operating Environment | Maximum Operating Temperature: 60°C / 140°F |
|---|
| Dimensions | 1.72in x 17in x 12in |
|---|
| First Listed on Newegg | September 21, 2026 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 5 years
- Limited Warranty period (labor): 5 years
- Read full details
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.com's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
LOADING...
The Vertiv VP5N31A0 is a horizontal 1U, 30A/120V switched rack PDU with 12 NEMA outlets, power monitoring, and remote outlet control, suited to IT teams managing server rooms or data-center racks that need to monitor loads and remotely power-cycle equipment.
Recommended For
- IT administrators managing a 120V server or network rack who need to remotely power-cycle individual devices without visiting the rack.
- Teams overseeing multiple rack devices that want to check rack-level power use and manage outlets remotely as part of routine operations.
- Rack operators who need a horizontal 1U PDU with 12 NEMA 5-20R outlets for compatible 120V equipment.
- IT teams that want to review rack power consumption and use outlet switching to help manage loads or reboot unresponsive equipment.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Rack-mounted IT equipment requiring switched power distribution across 12 NEMA outlets |
| Power Capacity And Electrical Ratings | 30A maximum input current, 100–120V input, 120V output, 50/60Hz input and output, and 2800W maximum output |
| Outlets And Switching | 12 NEMA outlets with switched power distribution |
| Overload Protection | Two 20A single-pole magnetic breakers rated at 10kAIC |
| Rack Mounting And Physical Specifications | Horizontal 1U rack form factor; 1.72 × 17 × 12 inches; 10 ft / 3 m cord; weighs 10 lb |
| Operating Environment | Maximum operating temperature of 60°C / 140°F |
| Compliance | RoHS compliant |
| Model Identifiers | Vertiv VP5N31A0 |
