Dual Channel HDMI Video Encoder with Loopout, H.264/H.265 Hardware Encoder, 2-Ch HDMI In / 2-Ch HDMI Out, SRT/RTSP/RTMP/WebRTC/GB28181/ONVIF Streaming Encoder, SATA 3.0 Storage
- -Dual HDMI Input with Independent Loopout
- Features 2× HDMI video inputs paired with 2× HDMI local loop-through outputs for zero-latency local monitoring while encoding and streaming.
- -Versatile Resolution & Encoding Performance
- Supports flexible encoding configurations including single-channel 1080p@30fps, dual-channel 4K@15fps, or dual-channel 1080P@60fps.
- -Multi-Protocol & Streaming Compatibility
- Natively supports a wide range of network streaming protocols: SRT, RTMP, RTSP, UDP-TS, HLS, WS-FLV, WS-RAW, WebRTC and ONVIF, ensuring seamless integration, security management, and live streaming platforms.
- -Expandable Local Storage (SATA 3.0)
- -Multi-Channel IP Stream Ingestion
- In addition to physical HDMI inputs, the device supports ingesting up to 6 network IP video streams for advanced multi-channel signal management and protocol conversion.
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
XSWEDR-D4KHDMI Audio Video Converter
The XSWEDR-D4KHDMI is a professional-grade audio video converter designed for demanding computer hardware environments. Equipped with 2 HDMI inputs and 6 IP stream inputs, it offers versatile connectivity for a range of AV sources. The device supports advanced video encoding capabilities, allowing simultaneous encoding of 1 channel at 4K@30fps and 1 channel at 1080p@30fps, or dual channels at 4K@15fps or 1080p@60fps. Compatible with H.264 and H.265 video formats and AAC audio encoding, it ensures high-quality, efficient streaming.
Features:
- Gigabit Ethernet port for reliable, high-speed network connectivity
- Supports multiple streaming protocols including SRT, RTSP, RTMP, UDP-TS, HLS, WS-FLV, WS-RAW, WebRTC, GB28181 Client, and ONVIF
- Remote management and remote upgrade capabilities via platform.xstrive.com
- SATA 3.0 expansion interface supporting up to 16TB for ample storage
- Wide operating temperature range (0°C ~ 70°C) for robust performance
With its compact design (270 x 216 x 45 mm) and manageable weight (1055 g), the XSWEDR-D4KHDMI is ideal for integration into professional AV and networked environments.
| Model | XSWEDR-D4KHDMI |
| Video input | 2-Channel HDMI input interface6-Channel network stream input |
| Audio Input | HDMI Embedded Audio |
| Video encoding capability | 1 × 4K@30fps + 1 × 1080p@30fps Or 2 × 4K@15fps Or 2 × 1080p@60fps |
| Network Interface | Gigabit Ethernet Interface |
| Expansion interface | SATA 3.0 |
| Network video output protocol | SRT/RTSP/RTMP/RTMPS/UDP-TS/HLS/WS-FLV/WS-RAW/WEBRTC/GB28181 client/ONVIF |
| Output video encoding format | H.264/H.265 |
| Output audio encoding format | AAC |
| Video encoding rate | 35Kbps ~ 80Mbps |
| Remote Upgrade | Support |
| Remote management | Support |
| Working Power | DC 12V |
| Working temperature | 0~70 |
| Dimensions | 27x21.6x4.5mm |
| Weight | 1055g |
