|Model||FAN MATE 2|
Directions For Use:
Connect FAN MATE 2 (adjustable fan speed connector) to the 3-pin connector of a fan as shown in Figure 1.
Connect FAN MATE 2 to the 3-pin CPU fan connector of the mainboard.
Turn on the computer after assembly is finished.
When the speed control knob is turned fully counter-clockwise, the fan speed is minimum, and the fan operates in silent mode. You can select the desired fan speed by turning the knob.
|Dimensions||2.76" x 1.02" x 1.02"|
|Features||Output Voltage: 5V - 11V +/- 2%|
Allowable Power: 6W or lower
Fan controller for adjusting the fan speed of a single fan according to user preference.
|Date First Available||July 02, 2004|
