Brand | ZOTAC |
---|---|
Model | IONITX-K-E |
Combo Type | Motherboard / CPU Combo |
CPU | Intel Atom 330 (1.6GHz, dual-core) |
---|---|
With Cooler | Yes |
CPU Socket Type | PBGA437 |
---|---|
CPU Type | Intel Atom |
FSB | 533MHz |
North Bridge | NVIDIA ION |
---|
Number of Memory Slots | 2x240pin |
---|---|
Memory Standard | DDR3 1066 |
Maximum Memory Supported | 4GB |
PCI Express x1 | 1 x PCI Express x1 |
---|---|
Mini Card Slots | 1 x Mini PCIe |
SATA | 4 x SATA 3.0Gb/s |
---|---|
SATA RAID | 0/1/0+1 |
Onboard Video Chipset | NVIDIA ION |
---|
Audio Channels | 6 Channels |
---|
Max LAN Speed | 10/100/1000Mbps |
---|
PS/2 | 1 |
---|---|
Video Ports | DVI |
HDMI | 1 x HDMI |
USB 1.1/2.0 | 6 x USB 2.0 |
Audio Ports | 3 Ports |
Onboard USB | 4 x USB 2.0 |
---|
Form Factor | Mini ITX |
---|
Date First Available | April 20, 2010 |
---|
Pros: Small, cheap, easy to install.
Cons: I agree with another poster that I've had to significantly lower settings to watch 1080p / large video files. (vlc has a lot of processing going on these days and can't keep up) In addition to their post, the research I've done indicates that putting card into the pciex1 won't help much :/
Overall Review: I'm upgrading to a i3 2100T and H67M-ITX. For what it's worth I THINK they sell a model that has a full pcie x 16 and would have gone that route probably originally had I realized it.
