ECS G43T-M LGA 775 Intel G43 HDMI Micro ATX Intel Motherboard

(30) Write a Review
  • Intel G43
  • Core 2 Quad / Core 2 Duo / Pentium Dual Core / Celeron Dual Core / Celeron 4xx processor
  • DDR2 800/667
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Specs
Reviews (30)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the ECS (EliteGroup) G43T-M

Model
Brand ECS
Model G43T-M
Supported CPU
CPU Socket Type LGA 775
CPU Type Core 2 Quad / Core 2 Duo / Pentium Dual Core / Celeron Dual Core / Celeron 4xx processor
FSB 1333/1066/800 MHz
Chipsets
Chipset Intel G43
South Bridge Intel ICH10
Onboard Video
Onboard Video Chipset Intel GMA X4500
Memory
Number of Memory Slots 4x240pin
Memory Standard DDR2 800/667
Maximum Memory Supported 8GB
Channel Supported Dual Channel
Expansion Slots
PCI Express 2.0 x16 1 x PCI Express 2.0 x16
PCI Express x16 None
PCI Express x1 2 x PCI Express x1
PCI Slots 1 x PCI Slot
Storage Devices
PATA 1 x ATA100 2 Dev. Max
Onboard Audio
Audio Chipset Realtek ALC888S
Audio Channels 8 Channels
Onboard LAN
LAN Chipset Atheros AR8121-L1E GigaLAN controller
Max LAN Speed 1Gbps
Rear Panel Ports
Back I/O Ports 1 x HDMI / 2 x PS/2 / 6 x USB 2.0/1.1
PS/2 2
Video Ports D-Sub
HDMI 1 x HDMI
USB 1.1/2.0 6 x USB 2.0
Audio Ports 6 Ports
Internal I/O Connectors
Onboard USB 6 x USB 2.0
Physical Spec
Form Factor Micro ATX
Dimensions (W x L) 9.6" x 9.6"
Power Pin 24 Pin
Additional Information
First Listed on Newegg October 09, 2008

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 2 years
