Manufacturer Warranty
Beyond any applicable Newegg return policy, this item is warranted independently by the product's Manufacturer. Below is a summary provided for convenience only and may not be accurate or current.
Use this link for full details.
- Manufacturer Limited Warranty period (parts): 3 years
- Manufacturer Limited Warranty period (labor): 2 years
Manufacturer Contact Info
|
-
- 5
-
- 63%
- 4
-
- 17%
- 3
-
- 2%
- 2
-
- 9%
- 1
-
- 9%
| Product Rating: |

|
| Total Reviews: |
58 |
Just plain bad
- Pros: When it works, nothing to complain about.
- Cons: Power-on issues, flakey USB, bad quality control.
- Other Thoughts: 2 out of 2 MBs have had issues. The first one reported a NB temp of 102 degrees C and was RMA'ed. The second one suffers from 2 different issues:
1. Every third power-on you need to hit reset to get the MB to make it past POST
2. USB is very flakey and sometimes needs multiple restarts for it to work fully.
Replacing this MB with one from another manufacturer. Done with Biostar.
Flakey.
- Pros: Without too much trouble I'm running Windows x64 @ 3.9GHz and can play games with very high stability.
- Cons: Most of the adapters have proven to be very flakey. To get most USB devices to recognize I must insert the device and then restart the computer.
One of my Network Adapters just died after a few months of use. I guess that's why they put two of them on there....
- Other Thoughts: I would not but this board after using it.
love it
- Pros: nice layout looks real nice works without a hitch
- Cons: t power doesnt load right on win 7 64 but not mobos fault
- Other Thoughts: core i7 920 , 12 gig gskill 1333 mhz ram, geforce gtx 275 graphics, cm storm scout case, and cooler master 700 w silent pro psu
| Model |
| Brand |
BIOSTAR |
| Model |
TpowerX58 |
| Supported CPU |
| CPU Socket Type |
LGA 1366 |
| CPU Type |
Core i7 (LGA1366) |
| FSB |
QPI 6.4GT/S |
| Chipsets |
| North Bridge |
Intel X58 |
| South Bridge |
Intel ICH10R |
| Memory |
| Number of Memory Slots |
6×240pin |
| Memory Standard |
DDR3 1866(O.C)/1600(O.C)/1333 |
| Maximum Memory Supported |
24GB |
| Channel Supported |
Triple Channel |
| Expansion Slots |
| PCI Express 2.0 x16 |
3 x PCI-E x16 2.0 Slot (x16, x16, x4) |
| PCI Express x1 |
1 |
| PCI Slots |
2 |
| Storage Devices |
| PATA |
1 x ATA100 2 Dev. Max |
| SATA 3Gb/s |
6 |
| SATA RAID |
0/1/5/10 |
| Onboard Video |
| Onboard Video Chipset |
None |
| Onboard Audio |
| Audio Chipset |
Realtek ALC888S |
| Audio Channels |
8 Channels |
| Onboard LAN |
| LAN Chipset |
Realtek 8111C |
| Second LAN Chipset |
Realtek 8111C |
| Max LAN Speed |
Dual 10/100/1000Mbps |
| Rear Panel Ports |
| PS/2 |
1 |
| USB 1.1/2.0 |
8 x USB 2.0 |
| IEEE 1394 |
1 x IEEE 1394a |
| eSATA |
2 x eSATA 3Gb/s |
| S/PDIF Out |
1 x Optical, 1 x Coaxial |
| Audio Ports |
6 Ports |
| Onboard USB |
| Onboard USB |
4 x USB 2.0 |
| Onboard 1394 |
| Onboard 1394 |
1x 1394a |
| Physical Spec |
| Form Factor |
ATX |
| Dimensions |
12.0" x 9.6" |
| Power Pin |
24 Pin |
| Manufacturer Warranty |
| Parts |
3 years limited |
| Labor |
2 years limited |
|
|
Reviewed By: Andreas on 12/24/2009
Tech Level: high - Ownership: 1 month to 1 year
