Item#: N82E16813138186

BIOSTAR TH55B HD LGA 1156 Intel H55 HDMI Micro ATX Intel Motherboard

  • Intel H55
  • Core i7 / i5 / i3 / Pentium (LGA1156)
  • DDR3 800/1066/1333/1600(OC)/1800(OC)/2000(OC)
ICON Loading...

Learn more about the Biostar TH55B HD

Model

Brand
BIOSTAR
Model
TH55B HD

Supported CPU

CPU Socket Type
LGA 1156
CPU Type
Core i7 / i5 / i3 / Pentium (LGA1156)

Chipsets

Chipset
Intel H55

Memory

Number of Memory Slots
4×240pin
Memory Standard
DDR3 800/1066/1333/1600(OC)/1800(OC)/2000(OC)
Maximum Memory Supported
16GB
Channel Supported
Dual Channel

Expansion Slots

PCI Express 2.0 x16
1
PCI Express x1
1
PCI Slots
2

Storage Devices

PATA
1 x ATA133 2 Dev. Max
SATA 3Gb/s
6

Onboard Video

Onboard Video Chipset
None

Onboard Audio

Audio Chipset
Realtek ALC662
Audio Channels
6 Channels

Onboard LAN

LAN Chipset
Realtek 8111DL
Max LAN Speed
10/100/1000Mbps

Rear Panel Ports

PS/2
1
Video Ports
D-Sub + DVI
HDMI
1 x HDMI
USB 1.1/2.0
4 x USB 2.0
Audio Ports
3 Ports

Internal I/O Connectors

Onboard USB
6 x USB 2.0

Physical Spec

Form Factor
Micro ATX
Dimensions
9.6" x 9.6"
Power Pin
24 Pin

Features

Features
5 Phases Power Design

Integrated HDMI/DVI interface with HDCP Supporting all HD formats including720P,1080i, 1080P. ( Required processors with Intel HD Graphics)

CPU integrated Graphics performance tunable via BIOS

BIOSTAR G.P.U (Green Power Utility) Technology for Energy Saving

BIOSTAR Toverclocker utility

Optimized to deliver full windows 7 Experience

Manufacturer Warranty

Parts
3 years limited
Labor
3 years limited

Quick Info

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years


Customer Reviews of the Biostar TH55B HD

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • Anonymous
  • 3/26/2011 10:17:41 AM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year

5 out of 5 eggsGood Stable Board

Pros: After 2 months, no problems. Paired with i3 3.2ghz, 8GB W7 Pro. Smooth operation, quick start-up. Good price for an Intel board. Biostar is never the fastest board, but always stable.

Cons: Need more USB's on back, Biostar has always been cheap with USB ports.

Other Thoughts: Would have liked USB 3.

Did you find this review helpful? Yes No

  • Ryan O.
  • 2/26/2011 4:15:04 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsGreat Mobo

Pros: Installation went great
I like the Tovercloacker software that allows you to change certain BIOS settings without having to actually go into the BIOS

Cons: My card reader periodically becomes nonfunctional, and I have to unplug it and plug it back in, but it is probably an issue with the card reader.

0 out of 1 people found this review helpful. Did you? Yes No

  • Anonymous
  • 2/23/2011 11:06:19 AM
  • Tech Level: High
  • Ownership: 1 week to 1 month

5 out of 5 eggsMissing Support *UPDATE***

Pros: Has excellent features for an unbeatable price. Best bang for the buck that I could find

*Support came through***

Cons: During the install I got a little overwhelmed and ranted on Biostar's support. They took a few days and I had to call in, but they ended up answering my questions. A nice fellow named Jackson talked me off the ledge.

Other Thoughts: I had several BSOD's on this build and the dumps were all different. It ended up being the power supply. My customer is being really cool about it so I took a chill and decided to right my wrong with this review. ...Maybe I should switch to decaff

0 out of 1 people found this review helpful. Did you? Yes No

  • Anonymous
  • 2/22/2011 7:47:19 AM
  • Tech Level: High
  • Ownership: 1 day to 1 week

1 out of 5 eggsMissing Support

Pros: Has excellent features for an unbeatable price. Best bang for the buck that I could find

Cons: Biostar Technical Support - Maybe they all took a fishing trip together. Please enjoy your vacation, but come back and help me. Oh, the manual is just a reprint of the notes included in the AMI Bios.

Other Thoughts: I purchased this board for a customer’s simple workstation plus VM guest. I chose a newer revision of i3-560 processor with Virtual and Hyperthreading tech – (BX80616I3560). I made the mistake when I checked Biostar’s supported CPU page which has the i5 3.33 GHz listed just above the i3. I made the mistake and I accept that, but I think it is fair to expect an answer from tech support. If the question requires research, just let me know so I can tell the customer.
If anyone can provide insight on this pairing that would be awesome. Troybme at gmail. Hopefully Biostar will see this and respond. I’m getting BSOD’s with a wide variety of debug results. Tried multiple clean installs and HDD, RAM, and CPU prime tests don’t point to anything else. I’m going to switch out the PSU and hopefully it will be the culprit.

Manufacturer Response:

Sorry to hear of the trouble, Biostar does monitor user feedback and will use repsond to assist your needs. Recommend that you contact our support staff at support@biostar-usa.com or call 626-581-1055 menu select 2 during business hours of 9 am to 5:30 pm pacific time M-F.

1 out of 3 people found this review helpful. Did you? Yes No

  • Cecile K.
  • 2/21/2011 7:35:25 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

4 out of 5 eggsLovely Product

Pros: I bought this in a combo deal with an i3. After downloading the newest bios onto a jump drive the setup and install of my new system was extremely easy. perfect for my needs.

Cons: The pci xpress slot is slightly loose. if i didnt have the card attached tightly it would lose contact with the top side and even wiggle when the tower is bumped.

Other Thoughts: overall a great buy. Biostar has let me down in the past, but not at all with this model.

Did you find this review helpful? Yes No

  • David M.
  • 2/12/2011 9:47:53 AM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggs

Pros: HDMI on board DVI on board lots of room to expand you don't need a lot of money to get a nice Mobo and a nice processor this board runs nice with the i3 I just use this combo in a build and the customer was happy when he heard that he could one day upgrade to the i7 another + was that I built this PC with 4GB RAM he was also happy to hear that he could later upgrade up to 16GB .....very happy with this purchase as was the person I built it for

Cons: none that I've found as of yet

Did you find this review helpful? Yes No

  • Yue F.
  • 2/8/2011 1:51:46 PM
  • Tech Level: Average
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsnice motherboard

Pros: Although an basic MB, it has a lot of features and utilities, like the built-in BIOS flasher and memory tester.
4 DRAM slots, that is the reason I pick it

Cons: only one 4pin fan connector

1 out of 2 people found this review helpful. Did you? Yes No

  • Anonymous
  • 1/2/2011 4:43:58 PM
  • Tech Level: Average
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsWorks just fine

Pros: +Worked right out of the box

+intel h55

+drivers installed just fine

Cons: have to OC ram to 1600 nothing huge

Other Thoughts: First computer I built had to use Intel h55 with the i3's graphics for a while which worked great. it can run source games on mostly high or medium settings at a decent frame rate.

Intel i3-540 3.06
Biostar TH55b
4GB RAM 1333 (OC 1600)
EVGA nVidia Geforce 9800gt
1TB Samsung HDD
corsair 650W

Did you find this review helpful? Yes No

  • Jason C.
  • 12/27/2010 8:03:46 PM
  • Tech Level: Average
  • Ownership: 1 month to 1 year
  • Verified Owner

3 out of 5 eggsNo Intel MEI Support - HDMI cannot be connected through a receiver

Pros: I bought this for the expansion possibilities (memory and HDD), the stability and the on board graphics, which made this MOBO light on the wallet.

Cons: This board does not support Intel MEI so it has to be directly attached the to TV and cannot be connected to a receiver - this is a major flaw that knocks this board from 5 to 3 eggs. From AVS Forum:
"The official word from Biostar was that *NONE* of their products supported PAVP, which means that any Biostar board will need to be attached to a single device for HDMI output."

1 out of 3 people found this review helpful. Did you? Yes No

  • Josue M.
  • 12/25/2010 11:32:37 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year

5 out of 5 eggsSimple and Great!!!

Pros: This motherboard is great, HDMI, VGA, DVI. was able to connect to monitors, great feature! up to 16 gigs, PCIe , Easy to over-clock .
What also do you need?

Cons: make sure that the motherboard is sitting properly! this is with any, but most people think is the motherboard when it's something else.

Other Thoughts: Make sure that you follow the basic principles when connecting any motherboard otherwise it may give you problems.

Did you find this review helpful? Yes No
