JetWay JI61G-ITX LGA 1155 Intel H61 HDMI USB 3.0 Mini ITX Intel Motherboard
- Intel H61
- Core i7 / i5 / i3 / Pentium / Celeron (LGA1155)
- DDR3 1333 / 1066
Specs
Reviews (6)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the JETWAY JI61G-ITX
| Brand | JetWay |
|---|---|
| Model | JI61G-ITX |
| CPU Socket Type | LGA 1155 |
|---|---|
| CPU Type | Core i7 / i5 / i3 / Pentium / Celeron (LGA1155) |
| Supported CPU Technologies | Turbo Boost Technology 2.0 |
| Chipset | Intel H61 |
|---|
| Onboard Video Chipset | Supported only by CPU with integrated graphic |
|---|
| Number of Memory Slots | 2x240pin |
|---|---|
| Memory Standard | DDR3 1333 / 1066 |
| Maximum Memory Supported | 8GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
|---|
| Audio Chipset | VIA VT1705 |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Realtek 8111E |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 3.0 / 4 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 x PS/2 keyboard/mouse port |
| Video Ports | D-Sub + DVI |
| HDMI | 1 x HDMI |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 2 x USB 2.0 |
|---|---|
| Other Connectors | 2 x Fan Headers 1 x HDMI_SPDIF Out Header 1 x 4-pin ATX 12V Power Connector 1 x 24-pin ATX Power Connector Front Panel Headers |
| Form Factor | Mini ITX |
|---|---|
| Dimensions (W x L) | 6.7" x 6.7" |
| Power Pin | 24 Pin |
| Features | Intel H61 Express Chipset Supports 2nd Generation Intel Core i3, i5, i7 Sandy Bridge Processors Supports Dual Channel DDR3-1333 up to 8GB PCI Express 2.0 x16 Expansion Slot 4 x SATA2 3Gb/s Ports Gigabit LAN, HD Audio, All Solid Capacitors 6 x USB 2.0 and 2 x USB 3.0 ports HDMI, DVI, and VGA Video Outputs Multi-Monitor Support in Windows 7 Mini-ITX Form Factor ( 170mm x 170mm ) |
|---|
| First Listed on Newegg | December 28, 2011 |
|---|
