ASRock 880G PRO3 AM3+ AMD 880G USB 3.0 HDMI ATX AMD Motherboard
- AMD 880G
- FX / Phenom II / Athlon II / Sempron 100 Series
- DDR3 2000(OC)/1866(OC)/1800(OC)/1600(OC)/1333/1066/800
Specs
Reviews (31)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the ASRock 880G PRO3
| Brand | ASRock |
|---|---|
| Model | 880G PRO3 |
| CPU Socket Type | AM3+ |
|---|---|
| CPU Type | FX / Phenom II / Athlon II / Sempron 100 Series |
| FSB | 2600 MHz |
| Chipset | AMD 880G |
|---|---|
| South Bridge | AMD SB850 |
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 2000(OC)/1866(OC)/1800(OC)/1600(OC)/1333/1066/800 |
| Maximum Memory Supported | 32GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 2 (x16, x4) |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 3 x PCI Slots |
| Serial ATA (SATA) | 5 x SATA 6Gb/s |
|---|---|
| SATA RAID | 0/1/0+1/5 |
| Onboard Video Chipset | ATI Radeon HD 4250 |
|---|
| Audio Chipset | Realtek ALC892 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Atheros AR8151 |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x D-Sub / 1 x DVI / 1 x HDMI / 1 x PS/2 / 2 x USB 3.1 Gen 1 / 4 x USB 2.0/1.1 / 5 x Audio Jacks |
|---|---|
| PS/2 | 1 |
| Video Ports | D-Sub + DVI |
| HDMI | 1 x HDMI |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| IEEE 1394 | 1 x IEEE 1394 |
| eSATA | 1 x eSATA 6Gb/s |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 5 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|---|
| Onboard 1394 | 1 x 1394 |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | Supports 8-Core CPU 100% All Solid Capacitor design Supports Dual Channel DDR3 1866(OC) Supports ATI Quad CrossFireX , CrossFireX and Hybrid CrossFireX Integrated AMD Radeon HD 4250 graphics, DX10.1 class iGPU, Shader Model 4.1 Multi VGA Output : D-Sub, DVI-D and HDMI 2 x USB 3.0, 5 x SATA3, 2 x IEEE 1394 Dr. Debug, Power/Reset/Clear CMOS Switch with LED Supports XFast USB, AXTU, UEFI, Instant Boot, Instant Flash, APP Charger, SmartView, Turbo UCC 7.1 CH HD Audio with Content Protection (Realtek ALC892 AUdio Codec), Supports Premium Blu-ray audio |
|---|
| First Listed on Newegg | March 29, 2011 |
|---|
