Spire SP-ATX-420WB&P4 420 W ATX12V ErP Lot 6 Power Supply
- ATX12V
- ErP Lot 6
- 90~120V/ 185~264V 50/60 Hz
- +3.3V@20A,+5V@25A,+12V1@15A,+12V2@15A,-12V@0.5A,+5VSB@2.0A
Specs
Reviews (1)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Spire SP-ATX-420WB&P4
| Brand | Spire |
|---|---|
| Model | SP-ATX-420WB&P4 |
| Type | ATX12V |
|---|---|
| Maximum Power | 420 W |
| Fans | 1 |
| PFC | No |
| Main Connector | 20+4Pin |
| +12V Rails | Yes |
| PCI-Express Connector | 1 x 6-Pin |
| SATA Power Connector | 1 |
| SLI | No |
| CrossFire | No |
| Modular | No |
| Power Good Signal | 100-500ms |
| Hold-up Time | 16ms min. |
| Efficiency | > 68% |
| Energy-Efficient | ErP Lot 6 |
| Over Voltage Protection | +12V trip point 13.4V - 15.6V | +5V trip point 5.74V - 7.0V | +3.3V trip point 3.76V - 4.3V |
| Overload Protection | Yes |
| Input Voltage | 90~120V/ 185~264V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 7A @ 115V, 4A @ 230V |
| Output | +3.3V@20A,+5V@25A,+12V1@15A,+12V2@15A,-12V@0.5A,+5VSB@2.0A |
| MTBF | >100,000 Hours |
| Approvals | UL, FCC, CE, CSA, TUV |
| Connectors | 1 x Main connector (20+4Pin) 1 x 12V(P4) 4 x peripheral 2 x SATA 1 x Floppy 1 x PCI-E |
| Features | Supports Intel Pentium 4, AMD Athlon XP and Athlon 64 3 Speed Variable Fan Speed Auto-Control I/O Short Circuit & Overload Protection Redundant Cooling System |
|---|
| First Listed on Newegg | August 22, 2007 |
|---|
