AMS DS-524SSBK 2.5" x4 SATA Backplane Module

  • 2.5" x4 SATA Backplane Module. SATA I/II/III & SSD compatible. Transfer speed up to 6Gbps (600MB/s). Fit into one 5.25" drive bay. Aluminum chassis. Color: Black
  • Multi 2.5" Drives to 5.25" Bay

  • Pin It
  • Email this page
ICON Loading...
  • Specifications
  • Warranty & Returns
  • Reviews

Learn more about the AMS (American Media Systems) DS-524SSBK

Model

Brand
AMS
Model
DS-524SSBK

Details

Mobile Rack Drives Support
Multi 2.5" Drives to 5.25" Bay
Mobile Rack Interface
SATA I/II/III
Specifications
2.5" x4 SATA Backplane Module.

SATA I/II/III & SSD compatible.

Transfer speed up to 6Gbps (600MB/s).

Fit into one 5.25" drive bay.

Aluminum chassis.

Color: Black
