Item#: 9SIA24G3KG0265

Intel 530 Series SSDSC2BW080A401 80GB 2.5 inch SATA3 Solid State Drive (MLC) - OEM

  • 2.5"
  • 80GB
  • SATA 6Gb/s

ICON Loading...
  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews

Mfr Part Number: SSDSC2BW080A401
•Capacity: 80 GB
•Form Factor: 2.5 inch
•Interface: SATA 6Gb/s
•NAND Flash: MLC
•Latency: Read - 80 µs; Write - 85 µs
•IOPS:?Random 8GB Read: up to 24,000 IOPS
?Random 8GB Write: up to 80,000 IOPS

•Bandwidth:?Sequential Read: 540 MB/s
?Sequential Write: 480 MB/s

•Vibration:?Operating: 2.17G (5 - 700 Hz) (Max)
?Non-operating: 3.13G (5 - 700 Hz) (Max)

•Shock:?Operating: 1500G @ 0.5ms (Max)
?Non-operating: 1500G @ 0.5ms (Max)

•MTBF: 1,200,000 Hours
•Power Consumption:?Active: 140 mW
?Idle: 55 mW

•Thickness: 7.0 mm
•Weight: Up to 78.0 g


Learn more about the Intel SSDSC2BW080A401

Warranty, Returns, And Additional Information

Customer Reviews of the Intel SSDSC2BW080A401

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • Touraj P.
  • 9/22/2014 6:07:59 AM
  • Ownership: 1 day to 1 week
  • Verified Owner

2 out of 5 eggsCompatibility Issues

Pros: Small, new tech.

Cons: not Compatible with my Z97-A ASUS board.

Other Thoughts: Intel and ASUS could do better.

1 out of 10 people found this review helpful. Did you? Yes No

  • Michael M.
  • 9/21/2014 11:53:23 AM
  • Ownership: 1 week to 1 month
  • Verified Owner

4 out of 5 eggsM.2 is incredible...

Pros: First time using an M2 SSD. Very easy to install and even easier to setup. I used Acronis to restore my OS - no problems. Found - restored - and was up and running within 5-10 minutes. Boot speed is not even something worth mentioning, by the time the BIOS beeps W7 is up.

Benchmark was slower than my M5 Plextor SSD, showing 99 write and 391 read. Thats on paper. Real world I cant tell a difference.

Inexpensive and more importantly, 5-year warranty.

Cons: None (yet).

1 out of 1 people found this review helpful. Did you? Yes No

  • Robert N.
  • 9/19/2014 10:41:28 PM
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggs

Pros: Fast, easier to install than SATA SSDs, low profile

Cons: none

Other Thoughts: If you have a motherboard that supports m.2, there is no reason to get a 2.5 inch SSD over this thing. There are no cables, it's very small, it's very fast, I can't think of a single disadvantage

1 out of 1 people found this review helpful. Did you? Yes No

  • Thomas V.
  • 8/29/2014 5:11:26 PM
  • Ownership: less than 1 day

5 out of 5 eggsForm Factors

Pros: I do not own this product yet. Purchasing for a MSI Z97-Gaming 3 mobo.

Cons: I had to dig to find the compatibility information for the motherboard, posted below.

Other Thoughts: Form Factors: M.2 80 mm (single- and double-sided)
− 2280-S2-B-M (80 GB and 180 GB)
− 2280-D2-B-M (120 GB and 360 GB)

The 2280 form is 80mm long.

0 out of 7 people found this review helpful. Did you? Yes No

  • Michael G.
  • 7/23/2014 12:51:13 PM
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggs

Pros: - Fast, and works great as a high speed cache/scratch drive.

-Small, fit great on ASUS Z97-Deluxe Mobo

Cons: -none

1 out of 1 people found this review helpful. Did you? Yes No

  • Ronald M.
  • 5/29/2014 8:57:15 AM
  • Ownership: less than 1 day

5 out of 5 eggsSpecs are easy to find

Pros: Newegg carries a vast amount of products and sometimes are unable to completely fill out all the information someone might want. A simple Google search for the product by the consumer can provide more detailed information that they "NEED".
The following information is provided straight from Intel's website and gives a clear listing of all product details. No hyperlink left due to Newegg's review policy but it was the top listing from a Google Search "intel SSDSCKGW080A401".

Intel® SSD 530 Series
(80GB, M.2 80mm SATA 6Gb/s, 25nm, MLC)
Sequential Read 540 MB/s
Sequential Write 480 MB/s
Random Read (8GB Span) 24000 IOPS
Random Write (8GB Span) 33000 IOPS
Latency - Read 80 µs
Latency - Write 85 µs
Power - Active 140 mW
Power - Idle 55 mW
Vibration - Operating 2.17 GRMS (5-700 Hz) Max
Vibration - Non-Operating 3.13 GRMS (5-700 Hz) Max
Shock (Operating and Non-Operating) 1000 G (Max) at 0.5 msec
Operating Temperature Range 0°C - 70°C
Weight < 10 grams
Mean Time Between Failures (MTBF) 1,200,000 Hours
Uncorrectable Bit Error Rate (UBER) <1 sector per 10^16 bits read
Warranty Period 5 yrs
Components Intel NAND Flash Memory Multi-Level Cell (MLC) Technology
Capacity 80 GB
Form Factor M.2 80mm
Interface SATA 6.0 Gb/s
Lithography 25 nm
Hardware Encryption AES 256 bit

Although this drive appears to have decent specs, I do not own this product yet so can not attest to it's performance.

Cons: Before you buy a product, if it does not have all the information you require, do a search for the product and if that proves unsuccessful, contact the vendor directly, otherwise it is your own fault for buying a product without doing proper research especially if you have a Technical Level 5 knowledge base.

31 out of 41 people found this review helpful. Did you? Yes No

  • Anonymous
  • 2/9/2014 11:26:23 AM
  • Ownership: 1 day to 1 week
  • Verified Owner

4 out of 5 eggsIts a new SSD!

Pros: It is thin! It is 22mm X 80mm. Fast read and write speeds.

Cons: Will not fit in the M.2 combo card in Asus Maximus VI boards, their motherboard coolers get in the way you need 22mm by 42mm at the most (refer to asus motherboard manual).
Had to buy a M2PS Dual M.2 (NGFF) SSD to SATA Adapter to use this with my Maximus VI Formula (Needed PCIe x1, because the x4 adapters require me to remove the ROG armor to use)

Other Thoughts: Vendors like Newegg should give out better specs, like dimensions (there's 30mm to 110mm) and connections. This card has an M and B key that can only fit in certain sockets (Socket 2 and 3 types). You NEED to know these things before hand it isnt like mxm 3.0b that has a uniform dimension and socket.
I feel like the only thing uniform in NGFF M.2 form facotrs are that they are 22mm wide.

29 out of 37 people found this review helpful. Did you? Yes No
