The TrendNet TPE-S44 Smart Switch offers faster access to more terminals on your network. The TPE-S44 offers Plug-and-Play operation with Windows, Mac, and Linux operating systems. Four of the switch's ports offer PoE for your Ethernet-powered devices. With support for 1K MAC address entries, you'll find support for any device you need to connect!
This 8-port switch features Auto-Negotiation, which optimizes performance by prioritizing network traffic and adjusting bandwidth and speed. Auto-MDIX technology detects and configures the appropriate connection type for your device to give you maximum speed for each terminal. The TPE-S44 utilizes Store-and-Forward switching, which verifies the integrity of data before forwarding it across the network, so you don't waste bandwidth on junk transmissions. The TrendNet TPE-S44 is a simple and economical way to deliver data and power!
-
- 5
-
- 83%
- 4
-
- 17%
- 3
-
- 0%
- 2
-
- 0%
- 1
-
- 0%
| Product Rating: |
|
| Total Reviews: |
6 |
8 months full load - running well
- Pros: all 8 jacks in use.
4 powering VOIP phones
4 plugged into additional devices (2 access pts, TRENDnet TPE-S88, printer)
Warm but not hot, has NOT gone down once in the 8 months its been installed (plugged into 1kw APC ups).
- Cons: None to speak of, though I could use a 12 port version (the 16 port is pricey and over kill so I'm just getting a cheap switch to add non-poe ports.)
- Other Thoughts: We have a few trendnet switches in the office. Never had a problem with any of them - very happy so far.
- Pros: Nice and very small. Good indicator lamping.
- Cons: Careful of the stats. It said 15 watts max per port but all four ports must be 30 watts or less. I’m powering cameras so I need the power. On the bright side as the unit is so cheap you can always buy additional units…
| Model | TPE-S44 |
| Switch Type | External |
| Network Management Type | Unmanaged |
| Jumbo Frames | No |
| Ports | 8 x RJ45 |
-
- 5
-
- 83%
- 4
-
- 17%
- 3
-
- 0%
- 2
-
- 0%
- 1
-
- 0%
| Product Rating: |
|
| Total Reviews: |
6 |
Solid but no wall mount holes!
- Pros: Great price, solid PoE delivery.
- Cons: It doesn't have wall mounting holes!
Nice PoE switch
- Pros: Inexpensive, worked out of box as advertised. Good metal chassis and build quality. Small, quiet.
- Cons: none
- Other Thoughts: Using it to run PoE IP security cameras
trendnet poe
- Pros: POE works just fine. Nice solid case. LED status of POE connectivity and over wattage
- Cons: Only 4 of the ports are POE
- Other Thoughts: Runs a little warm, so make sure it gets good ventilation
| Model |
| Brand |
TRENDnet |
| Model |
TPE-S44 |
| Spec |
| Switch Type |
External |
| Standards |
IEEE802.3, IEEE802.3u, IEEE802.3af |
| Network Management Type |
Unmanaged |
| Jumbo Frames |
No |
| Ports |
4 x 10/100Mbps Auto-MDIX POE Ports (1~4)
4 x 10/100Mbps Auto-MDIX Fast Ethernet Ports (5 ~8) |
| Speed |
10/100Mbps |
| Switching Method |
Store and Forward |
| Protocols |
CSMA/CD |
| PoE |
Yes |
| Stackable |
No |
| SNMP |
No |
| QoS |
No |
| LACP |
No |
| Layer |
2 |
| Port Mirroring |
No |
| Module Support |
No |
| Cabling |
10Mbps: Cat 3,4,5 Unshielded Cable
100Mbps: Cat 5, 5E, 6 Unshielded Cable |
| Topology |
Star |
| LEDs |
Per Unit: Power, Power MAX
Per Port: Link/Activity, Speed
PoE: PoE Status, Link/Activity, Speed |
| Power |
48V DC 0.8A External Power Adapter
6.3 watts max (no PD Device connected)
36.3 watts max (with 30w PoE Device connected) |
| Dimensions |
6.7" x 3.7" x 1.1" |
| Weight |
13.8 oz. |
| Temperature |
0ºC to 40ºC (32ºF to 104ºF) |
| Humidity |
10% - 90%, Non-condensing |
| Features |
| Features |
Power over Ethernet:
Up to 15.4 watts per Port; PD classification Identify
PoE Over Current Protection; PoE Circuit Sorting Protection
PoE Power on RJ-45 pin 3,6 for Power+ and pin 1,2 for Power
IEEE 802.3af Power over Ethernet (PoE) Standard Compliant
8 x 10/100Mbps Auto-Negotiation and Auto-MDIX Fast Ethernet RJ45 Ports
Built-in 4 PoE Ports (Port 1 ~ Port 4)
Supports PoE Power Maximum 15.4 watts for each POE port
Supports PoE Powered Device(PD) classification identify
Full Wire-Speed Non-Blocking Reception and Transmission
96Kbytes RAM Data Buffer and 1K entries MAC Address Table
Extensive Diagnostic LED’s on the Front Panel
IEEE 802.3x Flow Control for Full-Duplex Mode; Back Pressure Flow Control for Half-Duplex Mode |
| Packaging |
| Package Contents |
TPE-S44
USB Extension Cable
Driver Disk |
Introduction
The TrendNet TPE-S44 Smart Switch offers faster access to more terminals on your network. The TPE-S44 offers Plug-and-Play operation with Windows, Mac, and Linux operating systems. Four of the switch's ports offer PoE for your Ethernet-powered devices. With support for 1K MAC address entries, you'll find support for any device you need to connect!
This 8-port switch features Auto-Negotiation, which optimizes performance by prioritizing network traffic and adjusting bandwidth and speed. Auto-MDIX technology detects and configures the appropriate connection type for your device to give you maximum speed for each terminal. The TPE-S44 utilizes Store-and-Forward switching, which verifies the integrity of data before forwarding it across the network, so you don't waste bandwidth on junk transmissions. The TrendNet TPE-S44 is a simple and economical way to deliver data and power!
Highlights
 |
PoE Support
The TRENDnet TPE-S44 features 4 PoE (Power over Ethernet) ports, each of which can supply up to 15.4 watts of power, allowing you to attach any IEEE 802.3af-compliant device without an additional power source or cable, lowering installation costs.
|
 |
Half/full-duplex Compatible
With full-duplex support, the TRENDnet TPE-S44 works at a maximum 200Mbps on each RJ45 port (doubling the speed of normal half-duplex devices), and is also compatible with half-duplex mode. On top of that, each port supports Auto-negotiation and Auto-MDI/ MDI-X, which facilitate installation and troubleshooting respectively.
|
Quick Specs
| Brand | TRENDnet |
| Humidity | 10% - 90%, Non-condensing |
| Ports | 8 x RJ45 |
| Protocols | CSMA/CD |
| Speed | 10/100Mbps |
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3af |
| Switching Method | Store and Forward |
| Temperature | 0ºC to 40ºC (32ºF to 104ºF) |
| Topology | Star |
|
Reviewed By: JFish222 on 10/7/2008
Tech Level: high - Ownership: 1 month to 1 year
