Features: 12U with adjustable front and rear vertical rackmount rails
Hinged cabinet swings away from wall bracket for easy equipment access (swing direction is reversible)
Locking, reversible front door and locking, removable side panels
Fully assembled for quick installation
Weight Capacity: 150 lbs. (68 kgs) for 4Post mounting
100 lbs. (45 kgs) for 2Post center mounting
75 lbs. (34 kgs) for 2Post flush mounting
Specification: Rack Type: 4Post, 2Post
Equipment Depth: Shelf depth is 24.0" (610 mm). Equipment can be deeper
Mounting Depth Range: Mounting depth 2 - 30" deep (51 - 762 mm)
Overall Installation Depth:
Minimum overall depth is 24"
Maximum overall depth is the same as the rack's mounting depth
Shelf Surface Area: 17.125" x 24" (435 x 609.6 mm)
Shelf Type: Vented
10-32 and 12-24 screws
Cage nuts are provided for square hole racks
Front brackets: 2 adjustable position front rack flanges
Rear slide brackets: 2 adjustable position rear rack flanges
Compatible with the industry standard 3/8" (10 mm) square hole racks
Compatible with all s...
Weight Capacity: 2Post center mount
1U: 45 lbs (20.4 kgs)
2Post flush mount
1U: 30 lbs (13.64 kgs)
Specification: Rail OEM: All Purpose
Telco Racks, 2Post racks, relay racks.
Compatible with APC, CPI Chatsworth, Bud and most other racks.
Hole Type: Compatible with all standard threads including 10-32, 12-24 and metric M6
Rail Type: Fixed. Supports center and flush mount installations
Mounting Depth Range: Mounting depth from 2 - 31.5" (51 - 800 mm)
Maximum: 17.625 (448 mm)
1U Minimum: 16.625" (422 mm)
The rack rails support flange is 23 1/2" (597 mm) long.
The rack rail will support servers computers or equipment up to 35" (889 mm) deep.
Overall Installation Depth: Maximum overall depth is the same as the rack's mounting depth
Cable Management: Cable ma...
