Specifications: Dimensions: 16.51mm x 10.16mm
Type: Compliant to TPM Main Specification, Family "2.0", Level 00, Revision 01.16
- SPI interface
- Meeting Intel TXT, Microsoft Windows and Google Chromebook certification criteria for successful platform qualification
- Random Number Generator (RNG) according to NIST SP800-90A
- Full personalization with Endorsement Key (EK) and EK certificate
- Standard (-20..+85°C) and Enhanced temperature range (-40..+85°C)
- PG-VQFN-32-13 or PG-UQFN-32-1 package
- Pin compatible to OPTIGA TPM SLB 9670 TPM1.2 version
- Optimized for battery operated devices: low standby power consumption (typ. 110µA)
- 24 PCRs (SHA-1 or SHA-256)
- 7206 Byte free NV memory
- Up to 3 loaded sessions (TPM_PT_HR_LOADED_MIN)
- Up to 64 active sessions (TPM_PT_ACTIVE_SESSIONS_MAX)
- Up to 3 loaded transient Objects (...
Specifications: IC: Nuvoton NPCT650
Type:
TCG Compliance:
TCG PC Client Platform TPM Profile (PTP) Specification; Family 2.0 (Trusted Platform Module Library; Family 2.0)
TCG PC Client Specific TPM Interface Specification (TIS), Version 1.3 (TPM Main Specification; Family 1.2 Revision 116)
Low standby power consumption
Defends Against:
Fault injection attacks
Physical attacks
Side channel attacks
Differential fault analysis attacks
RNG attacks
Sensor and test mode attacks
Dictionary attacks
OS:
Support Windows 8.1, Windows 10 Bitlocker.
Supported on H110, X299, AM4, TR4 and newer platform motherboards.
Specifications: Controller: ASPEED AST2500
Feature: Base Board Management Controller (IPMI2.0 with iKVM support)
VGA (1920x1200@60Hz 32bpp)
Memory: 2 SPI flash ROM 32MB
1 DDR4 SDRAM 4Gb
Physical Status
Form Factor: Low profile PCIe add-in-card
Dimensions: 168.45 x 68.9 mm
I/O
Upstream interface: PCI Express2.0 x1
External: 1 RJ45 via Realtek RTL8211E for dedicated IPMI LAN (10/100/1000 Mbps), 1 DB-15 (VGA)
Internal connectors: 2 SMBus header
1 x PMBus header
1 x IPMB header
1 x BMC reset
1 x BMC debug header
1 x V BIOS or system BIOS ROM
2 x BMC ROM
1 x Dual ROM select header
1 x TPM (13-pin, LPC)
1 x LPC header (13-pin)
2 x Fan header
1 x USB2.0 (5-pin): KVM and standby power
1 x header (18-pin): GPIO, NCSI
1 x header (18-pin): case open, system fail, GPIO, SMBus, PECI, voltage monitoring
1 x COM port (9-pin)
1 x micro-SD connector
1 x ...
Specifications: IC: INFINEON SLB9665
Type:
TCG Compliance:
TCG PC Client Platform TPM Profile (PTP) Specification; Family 2.0 (Trusted Platform Module Library; Family 2.0)
TCG PC Client Specific TPM Interface Specification (TIS), Version 1.3 (TPM Main Specification; Family 1.2 Revision 116)
Low standby power consumption
Defends Against:
Fault injection attacks
Physical attacks
Side channel attacks
Differential fault analysis attacks
RNG attacks
Sensor and test mode attacks
Dictionary attacks
Support OS:
Support Windows 8.1, Windows 10 Bitlocker.
Supported on X299, AM4 and newer platform motherboards.
