Specifications: Audio: Supports high-definition audio (HD) 5.1/6.1/7.1 surround sound: Dolby TrueHD, DTS-HD Master Audio LPCM channels up to 7.1 channels 192 kHz
Operating Humidity: 0 to 80% relative humidity
Operating Temperature: 32° to 122° F (0° to 50° C)
PoE: Complies with IEEE 802.3at standard, Class 4;
Power: Normal input: 48 VDC;
Input Range: 36 to 57 VDC
Power: (1) External 5 VDC, 3 A
Power Consumption: POE: 10.5 W
Storage Temperature: -4° to +140° F (-20° to +60° C)
User Controls:
B1: Set/Reset Pushbutton;
B2: Function Selection Pushbutton;
Rotary switch: Select from 16 Video Channels (HEX 0–F), Paired TX and RX units must use the same channel
Specifications: Connectors : 1 x DB25 M, 1 x DB25 F
Data Format: 7 or 8 bits; 1 or 2 stop bits; even, odd, or no parity
Data Rate: 300, 600, 1200, 2400, 4800, 9600, 19,200, 38,400 bps
Interface: EIA RS-232 async serial (autosensing DTE/DCE) and IBM PC parallel
