Specification: Rail OEM: All Purpose
Server Compatibility: Apple, Dell, HP and IBM
Rack Type:
Mounts in any type of 4Post rack
2Post versions are also available
Hole Type:
Compatible with the industry standard 3/8" square hole racks
Cage nuts included for square hole mounting
Compatible with all standard round (non-threaded) holes
Compatible with all standard threads including 10-32, 12-24 and metric M6
Rail Type: Fixed
Mounting Depth Range: 0" to 31.75" (0 mm to 806.5 mm)
Equipment Width:
Maximum: 17.625 (448 mm)
1U Minimum: 16.625" (422 mm)
Equipment Depth:
The rack rails support flange is 23 1/2" (597 mm) long.
The rack rail will support servers computers or equipment up to 35" (889 mm) deep.
Overall Installation Depth: Maximum overall depth is the same as th...
Specification: Rail OEM: All Purpose
Server Compatibility: Apple, Dell, HP and IBM
Rack Type:
Mounts in any type of 4Post rack
2Post versions are also available
Hole Type:
Compatible with the industry standard 3/8" square hole racks
Cage nuts included for square hole mounting
Compatible with all standard round (non-threaded) holes
Compatible with all standard threads including 10-32, 12-24 and metric M6
Rail Type: Fixed
Mounting Depth Range: 0" to 31.75" (0 mm to 806.5 mm)
Equipment Width:
Maximum: 17.625 (448 mm)
2U Minimum: 16.375" (416 mm)
Equipment Depth:
The rack rails support flange is 23 1/2" (597 mm) long.
The rack rail will support servers computers or equipment up to 35" (889 mm) deep.
Overall Installation Depth: Maximum overall depth is the same as the ...
Weight Capacity: 150 lbs. (68 kgs) for 4Post mounting
100 lbs. (45 kgs) for 2Post center mounting
75 lbs. (34 kgs) for 2Post flush mounting
Specification: Rack Type: 4Post, 2Post
Equipment Depth: Shelf depth is 24.0" (610 mm). Equipment can be deeper
Mounting Depth Range: Mounting depth 2 - 30" deep (51 - 762 mm)
Overall Installation Depth:
Minimum overall depth is 24"
Maximum overall depth is the same as the rack's mounting depth
Shelf Surface Area: 17.125" x 24" (435 x 609.6 mm)
Shelf Type: Vented
Included Hardware:
10-32 and 12-24 screws
Cage nuts are provided for square hole racks
Front brackets: 2 adjustable position front rack flanges
Rear slide brackets: 2 adjustable position rear rack flanges
Hole Type:
Compatible with the industry standard 3/8" (10 mm) square hole racks
Compatible with all s...
Weight Capacity: 2Post center mount
1U: 45 lbs (20.4 kgs)
2Post flush mount
1U: 30 lbs (13.64 kgs)
Specification: Rail OEM: All Purpose
Rack Type:
Telco Racks, 2Post racks, relay racks.
Compatible with APC, CPI Chatsworth, Bud and most other racks.
Hole Type: Compatible with all standard threads including 10-32, 12-24 and metric M6
Rail Type: Fixed. Supports center and flush mount installations
Mounting Depth Range: Mounting depth from 2 - 31.5" (51 - 800 mm)
Equipment Width:
Maximum: 17.625 (448 mm)
1U Minimum: 16.625" (422 mm)
Equipment Depth:
The rack rails support flange is 23 1/2" (597 mm) long.
The rack rail will support servers computers or equipment up to 35" (889 mm) deep.
Overall Installation Depth: Maximum overall depth is the same as the rack's mounting depth
Cable Management: Cable ma...
Features: 12U OF RACKABLE SPACE: This 12U open frame desktop server rack is perfect for mounting shallow EIA 19" equipment such as switches patch panels and small AV devices.^^COMPACT AND SPACE-SAVING DESIGN: The rack's small footprint makes it ideal for offices with limited space. Its free-standing design and rubber feet prevent
