ABIT AN8-ULTRA 939 NVIDIA nForce4 Ultra ATX AMD Motherboard
- NVIDIA nForce4 Ultra
- Athlon 64 FX / Athlon 64
- DDR 400
Specs
Reviews (123)
Learn more about the Universal abit USA AN8-ULTRA
| Brand | ABIT |
|---|---|
| Model | AN8-ULTRA |
| CPU Socket Type | 939 |
|---|---|
| CPU Type | Athlon 64 FX / Athlon 64 |
| FSB | 1000 MHz |
| Chipset | NVIDIA nForce4 Ultra |
|---|
| Number of Memory Slots | 4x184pin |
|---|---|
| Memory Standard | DDR 400 |
| Maximum Memory Supported | 4GB |
| Channel Supported | Dual Channel |
| PCI Express x16 | 1 x PCI Express x16 |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 3 x PCI Slots |
| PATA | 2 x ATA100 4 Dev. Max |
|---|---|
| SATA RAID | 0/1/0+1 |
| Audio Chipset | AC97 Codec |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | NV GbE LAN |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x Optical S/PDIF Out / 2 x PS/2 / 4 x USB 2.0/1.1 / 6 x Audio Jacks |
|---|---|
| PS/2 | 2 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| IEEE 1394 | 1 x IEEE 1394a |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 6 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|---|
| Onboard 1394 | 1 x 1394a |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | Exclusive ABIT Engineered motherboard technology designed for unprecedented power, convenience, and control over your PC |
|---|
| Date First Available | July 06, 2005 |
|---|
