AMD Ryzen™ Threadripper™ Processors for Desktop Workstations

AMD Ryzen™ Threadripper™ processors deliver battle-tested performance and capability to enable artists, architects, and engineers with the ability to get more done in less time.

Accelerate Your Vision and Advance Demanding Workloads

When deadlines are non-negotiable, professional artists, architects, and engineers need a workstation that excels. AMD Ryzen™ Threadripper™ PRO processors offer a highly expandable platform with unmatched performance, enterprise-class security, and exceptional manageability. Empower your team like never before.

Increase Productivity

Save up to 27 minutes for every hour of productivity on the fastest workstation processors on the market.¹

Designed for artists, architects, and engineers, these processors excel in both multi-threaded and lightly threaded workflows, offering exceptional power, performance, and platform expandability built on the leading Zen 4 architecture.

Create Without Restraint

Fast-track creative workflows with the performance, value, and reliability of next-gen professional GPUs and high-speed storage devices.

AMD Ryzen Threadripper processors support a range of advanced workstation configurations to meet the needs of cutting-edge visual work.

Accelerate AI Workflows

Enhance your engineering, creative, scientific and development workfloads and avoid paying expensive cloud subscription costs, with on-device genAI like LLM and diffusion models.

From conception to final production, integrate advanced AI tools into every phase of your project.

Advancing Productivity Across Industries

Architecture, Engineering, & Construction

Accelerate architectural workflows like editing point clouds, rendering and virtual reality.

Design & Manufacturing

Reduce simulation and render times while the system stays productive.

Media & Entertainment

Tear through complex rendering and VFX workloads while increasing creative iterations.

Software & Sciences

Reduce compile times and boost scientific discovery with rapid simulation and analysis.

Deploy Windows Enterprise Autopilot up to 41% faster²

All AMD Ryzen PRO processors offer 18 months of planned software stability, 24 months of planned availability, and an enhanced platform validation process to ensure enterprise-grade quality and long-term stability.

Choose the AMD Threadripper Platform to Fit Your Needs

Choose the AMD TRX50 chipset for focused, full spectrum performance with up to 80 PCIe lanes and 4-channel memory and choose the AMD WRX90 chipset for the ultimate PCIe® 5.0 expandability, 8-channel memory, and enterprise class manageability and security.

	AMD WRX90 Platform	AMD TRX50 Platform
PRO Manageability	Yes
PRO Security Features	Yes
Overclocking Support	Yes (not enabled on OEM systems)	Yes
PCIe® Lanes (Total/Usable)	148/144 (w/ up to 128 PCIe® 5.0)	92/88 (w/ up to 48 PCIe® 5.0)
Socket	sTR5	sTR5
PCIe® 5.0 Lanes	128	80
Memory Configuration	8-Channel, up to 2TB (overclockable RDIMM)	4-Channel, up to 1TB (overclockable RDIMM)
Processor Support	AMD Ryzen Threadripper PRO 9000 WX-Series Processors	AMD Ryzen Threadripper 9000 Series Processors

Comparison

Ryzen Threadripper PRO 9000 WX-Series

Name	Graphics Model	# of CPU Cores	# of Threads	Max. Boost Clock³	Base Clock⁴	Thermal Solution (PIB)	Default TDP
AMD Ryzen™ Threadripper™ PRO 9995WX	Discrete Graphics Card Required	96	192	Up to 5.4 GHz	2.5 GHz	Not Included	350W
AMD Ryzen™ Threadripper™ PRO 9985WX	Discrete Graphics Card Required	64	128	Up to 5.4 GHz	3.2 GHz	Not Included	350W
AMD Ryzen™ Threadripper™ PRO 9975WX	Discrete Graphics Card Required	32	64	Up to 5.4 GHz	4 GHz	Not Included	350W
AMD Ryzen™ Threadripper™ PRO 9965WX	Discrete Graphics Card Required	24	48	Up to 5.4 GHz	4.2 GHz	Not Included	350W
AMD Ryzen™ Threadripper™ PRO 9955WX	Discrete Graphics Card Required	16	32	Up to 5.4 GHz	4.5 GHz	Not Included	350W
AMD Ryzen™ Threadripper™ PRO 9945WX	Discrete Graphics Card Required	12	24	Up to 5.4 GHz	4.7 GHz	Not Included	350W

Ryzen Threadripper 9000 Series

Name	Graphics Model	# of CPU Cores	# of Threads	Max. Boost Clock³	Base Clock⁴	Thermal Solution (PIB)	Default TDP
AMD Ryzen™ Threadripper™ 9980X	Discrete Graphics Card Required	64	128	Up to 5.4 GHz	3.2 GHz	Not Included	350W
AMD Ryzen™ Threadripper™ 9970X	Discrete Graphics Card Required	32	64	Up to 5.4 GHz	4 GHz	Not Included	350W
AMD Ryzen™ Threadripper™ 9960X	Discrete Graphics Card Required	24	48	Up to 5.4 GHz	4.2 GHz	Not Included	350W

Notes:

1. Based on AMD performance lab testing as of July, 2023, using the SPEC Workstation 3.1 Media and Entertainment metric, SPEC Workstation 3.1 Product Development PTC Creo subset metric, SPEC Workstation 3.1 Life Sciences overall metric, SPEC Workstation 3.1 Financial Services overall metric, SPEC Workstation 3.1 Energy overall metric, the V-Ray CPU performance benchmark, the PugetBench for Adobe AfterEffects v0.95.7 benchmark, the PugetBench for Premiere Pro v0.98.0 benchmark, the SPECapc Maya 2023 CPU composite metric, the Unreal Engine 5.1 compilation benchmark, the Chromium Compilation 115.0.5740 benchmark, the SPECapc for Solidworks 2022 CPU composite metric, the Keyshot CPU rendering benchmark, the Puget Metashape total Processing time (Rock Model) benchmark, and the Corona rendering (Rays/Sec) benchmark, Blender Rendering Benchmark, to compare the performance of AMD Ryzen Threadripper PRO 5995WX, 5975WX, 5965WX, 5955WX, 5945WX processors in reference systems configured with 8x64GB DDR4, NVIDIA Quadro RTX A5000, 1TB SSD, Win 11 vs. a similarly configured BOXX workstation with Intel Xeon w9-3495X, w9-3475X, w7-3455X, w5-3435X, w5-3425X, w7-2495X, w7-2465X processors Workstation manufacturers may vary configurations, yielding different results. Results may vary. CGP-45

2. Based on AMD performance lab testing as of August, 2023, using the SPECapc for Solidworks 2022 CPU composite metric to compare the performance of the full stack of AMD Ryzen Threadripper PRO 7000 WX-Series processors and the AMD 5965WX and 5955WX processors in a reference system configured with 8x32GB DDR5, NVIDIA Quadro RTX A5000 graphics, 1TB SSD, Win 11 vs.similarly configured BOXX workstations with the full stack of Intel Xeon w-3400 series and and the Intel w7-2495X and the Intel w7-2465X processors. Workstation manufacturers may vary configurations, yielding different results. Results may vary. SPP-15

3. Max boost for AMD processors is the maximum frequency achievable by a single core on the processor running a bursty single-threaded workload. Max boost will vary based on several factors, including, but not limited to: thermal paste; system cooling; motherboard design and BIOS; the latest AMD chipset driver; and the latest OS updates. GD-150

4. Represents the average effective base frequency of all cores.
