HPE Aruba 8325-48Y8C - switch - 48 ports - managed - rack-mountable JL624A
- Expansion / Connectivity: 48 x 10/25Gbit LAN
- Power: Internal power supply - hot-plug
- Miscellaneous: 6 x fans
- Dimensions & Weight: 17.3 in
- HPE Aruba 8325-48Y8C - Switch - L3 - managed - 48 x 10/25 Gigabit SFP+ / SFP28 + 8 x 40/100 Gigabit QSFP+ / QSFP28 - front to back airflow - rack-mountable - TAA Compliant
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Product
General
Device Type Switch - 48 ports - L3 - managed
Enclosure Type Front to back airflow rack-mountable 1U
Subtype 100 Gigabit Ethernet
Ports 48 x 10/25 Gigabit SFP+ / SFP28 + 8 x 40/100 Gigabit QSFP+ / QSFP28
Performance Switching capacity: 6.4 Tbps | Throughput: 1.905 Mpps
Capacity Virtual interfaces (VLANs) per port for 802.1 q: 4096
Jumbo Frame Support 9KB
Routing Protocol OSPF, EGP, BGP-4, BGP, IGMPv2, IGMP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, OSPFv3, static IPv6 routing, ECMP, policy-based routing (PBR), MLD, MSTP, RSTP, STP
Remote Management Protocol SNMP, RMON, SNMP 3, SNMP 2c, TFTP, SSH, CLI, SFTP, NTP
Encryption Algorithm FIPS 140-2
Authentication Method Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v. 2 (SSH2)
Features Routing, DHCP support, VPN support, ARP support, VLAN support, IGMP snooping, port mirroring, manageable, IPv6 support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Link Aggregation Control Protocol (LACP), fan tray, redundant hot swappable fans, packet storm protection, Strict Priority (SP), Loopback, VXLAN tunnel endpoints (VTEP) support, Protocol Independent Multicast (PIM)
Compliant Standards IEEE 802.3 z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1 p, IEEE 802.3 ad (LACP), IEEE 802.1 w, IEEE 802.3 ae, IEEE 802.1 s, IEEE 802.1 t, IEEE 802.1 ab (LLDP), IEEE 802.1 ak, IEEE 802.3 ba, IEEE 802.1AX
Expansion / Connectivity
Interfaces 48 x 10/25Gbit LAN | 8 x 100Gbit/40Gbit LAN
Power
Power Device Internal power supply - hot-plug
Installed Qty 2 (installed) / 2 (max)
Power Redundancy Yes
Power Redundancy Scheme N+1
Power Provided 650 Watt
Voltage Required AC 120/230 V (50/60 Hz)
Miscellaneous
Included Accessories 6 x fans
Compliant Standards RoHS, WEEE
TAA Compliant Yes
Dimensions & Weight
Width 17.3 in
Depth 21.1 in
Height 1.7 in
Weight 22.05 lbs
Specifications
General
Device Type Switch - 48 ports - L3 - managed
Enclosure Type Front to back airflow rack-mountable 1U
Subtype 100 Gigabit Ethernet
Ports 48 x 10/25 Gigabit SFP+ / SFP28 + 8 x 40/100 Gigabit QSFP+ / QSFP28
Performance Switching capacity: 6.4 Tbps | Throughput: 1.905 Mpps
Capacity Virtual interfaces (VLANs) per port for 802.1 q: 4096
Jumbo Frame Support 9KB
Routing Protocol OSPF, EGP, BGP-4, BGP, IGMPv2, IGMP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, OSPFv3, static IPv6 routing, ECMP, policy-based routing (PBR), MLD, MSTP, RSTP, STP
Remote Management Protocol SNMP, RMON, SNMP 3, SNMP 2c, TFTP, SSH, CLI, SFTP, NTP
Encryption Algorithm FIPS 140-2
Authentication Method Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v. 2 (SSH2)
Features Routing, DHCP support, VPN support, ARP support, VLAN support, IGMP snooping, port mirroring, manageable, IPv6 support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Link Aggregation Control Protocol (LACP), fan tray, redundant hot swappable fans, packet storm protection, Strict Priority (SP), Loopback, VXLAN tunnel endpoints (VTEP) support, Protocol Independent Multicast (PIM)
Compliant Standards IEEE 802.3 z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1 p, IEEE 802.3 ad (LACP), IEEE 802.1 w, IEEE 802.3 ae, IEEE 802.1 s, IEEE 802.1 t, IEEE 802.1 ab (LLDP), IEEE 802.1 ak, IEEE 802.3 ba, IEEE 802.1AX
Expansion / Connectivity
Interfaces 48 x 10/25Gbit LAN | 8 x 100Gbit/40Gbit LAN
Power
Power Device Internal power supply - hot-plug
Installed Qty 2 (installed) / 2 (max)
Power Redundancy Yes
Power Redundancy Scheme N+1
Power Provided 650 Watt
Voltage Required AC 120/230 V (50/60 Hz)
Miscellaneous
Included Accessories 6 x fans
Compliant Standards RoHS, WEEE
TAA Compliant Yes
Dimensions & Weight
Width 17.3 in
Depth 21.1 in
Height 1.7 in
Weight 22.05 lbs
