ASRock 880GM-LE AM3 AMD 880G Micro ATX AMD Motherboard
OUT OF STOCK.
- AMD 880G
- Phenom II / Athlon II / Sempron
- DDR3 1800(OC)/1600(OC)/1333/1066/800
Specs
Reviews
Learn more about the ASRock 880GM-LE
| Brand | ASRock |
|---|---|
| Model | 880GM-LE |
| CPU Socket Type | AM3 |
|---|---|
| CPU Type | Phenom II / Athlon II / Sempron |
| FSB | 2600 MHz |
| Chipset | AMD 880G |
|---|---|
| South Bridge | AMD SB710 |
| Number of Memory Slots | 2×240pin |
|---|---|
| Memory Standard | DDR3 1800(OC)/1600(OC)/1333/1066/800 |
| Maximum Memory Supported | 8GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| PATA | 1 x ATA133 2 Dev. Max |
|---|---|
| SATA 3Gb/s | 6 x SATA 3Gb/s |
| SATA RAID | 0/1/10/JBOD |
| Onboard Video Chipset | ATI Radeon HD 4250 |
|---|
| Audio Chipset | Realtek ALC662 |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Realtek 8111DL |
|---|---|
| Max LAN Speed | 10/100/1000Mbps |
| PS/2 | 2 |
|---|---|
| Video Ports | D-Sub + DVI |
| USB 1.1/2.0 | 6 x USB 2.0 |
| Audio Ports | 6 Ports |
| Onboard USB | 3 x USB 2.0 headers (support 6 USB 2.0 ports) |
|---|
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.6" x 7.8" |
| Power Pin | 24 Pin |
| Features | Phenom II X6 6-Core CPU Ready Supports AMD OverDrive with ACC feature (Advanced Clock Calibration) Supports Dual Channel DDR3 1800(OC) Integrated AMD Radeon HD 4250 graphics, DX10.1 class iGPU, Shader Model 4.1, Max. shared memory 512MB Dual VGA Output options: DVI-D and D-Sub ports by independent display controllers Supports ASRock Instant Boot, Instant Flash, OC Tuner, IES, OC DNA ErP/EuP Ready |
|---|
| Date First Available | May 18, 2010 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 1 year
- Read full details
Return Policies
- Return for refund within: 30 days
- Return for replacement within: 30 days
- This item is covered by Newegg.com's Standard Return Policy
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-909-590-8308
- Support Email: support@asrockamerica.com
- Support Website
- View other products from ASRock
LOADING...
LOADING...

















Eggxpert Review
Pros: This just went into a customer's build. I've been really impressed lately with the value and quality I've been getting from ASROCK boards. This one is no exception. Lots of USB headers and everything worked the first time without any trouble
Cons: Nothing really
Overall Review: I didn't try out the core unlocker feature on this board as I'm looking for reliability in a customer's build. If I had more time to test it for stability after the unlock I might have attempted it but I was on a tight schedule.
