ASRock 880GMH/U3S3 AM3+ AMD 880G USB 3.0 HDMI Micro ATX AMD Motherboard
- AMD 880G
- FX / Phenom II / Athlon II / Sempron 100 Series
- DDR3 2000(OC) / 1866(OC) / 1800(OC) / 1600(OC) / 1333 / 1066 / 800
Specs
Reviews (20)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the ASRock 880GMH/U3S3
| Brand | ASRock |
|---|---|
| Model | 880GMH/U3S3 |
| CPU Socket Type | AM3+ |
|---|---|
| CPU Type | FX / Phenom II / Athlon II / Sempron 100 Series |
| FSB | 2600 MHz |
| Chipset | AMD 880G |
|---|---|
| South Bridge | AMD SB710 |
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 2000(OC) / 1866(OC) / 1800(OC) / 1600(OC) / 1333 / 1066 / 800 |
| Maximum Memory Supported | 32GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| PATA | 1 x ATA133 2 Dev. Max |
|---|---|
| Serial ATA (SATA) | 2 x SATA 6Gb/s |
| SATA RAID | 5 x SATA2 3.0 Gb/s support RAID (0, 1, 10 and JBOD) |
| Onboard Video Chipset | ATI Radeon HD 4250 |
|---|
| Audio Chipset | Realtek ALC892 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Atheros AR8151 |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x D-Sub / 1 x DVI / 1 x HDMI / 1 x PS/2 / 2 x USB 3.1 Gen 1 / 4 x USB 2.0/1.1 / 5 x Audio Jacks |
|---|---|
| PS/2 | 1 |
| Video Ports | D-Sub + DVI |
| HDMI | 1 x HDMI |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| eSATA | 1 x eSATA 3Gb/s |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 5 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|---|
| Other Connectors | 1 x IR header 1 x CIR header 1 x COM port header CPU/Chassis/Power FAN connector 24 pin ATX power connector 4 pin 12V power connector CD in header Front panel audio connector |
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.6" x 9" |
| Power Pin | 24 Pin |
| Features | Supports AM3+ Processor, 8-Core CPU Ready 100% All Solid Capacitor design Supports Dual Channel DDR3 2000(OC) Supports ATI Hybrid CrossFireX Integrated AMD Radeon HD 4250 graphics, DX10.1 class iGPU, Shader Model 4.1 Multi VGA Output : D-Sub, DVI-D and HDMI 2 x USB 3.0, 2 x SATA3, C.C.R. (Combo Cooler Retention Module) Supports XFast USB, AXTU, Graphical UEFI, Instant Boot, Instant Flash, APP Charger, SmartView 7.1 CH HD Audio with Content Protection (Realtek ALC892 AUdio Codec) |
|---|
| First Listed on Newegg | September 01, 2011 |
|---|
