ASRock 990FX Extreme3 AM3+ AMD 990FX USB 3.0 ATX AMD Motherboard with UEFI BIOS
REFURBISHED Product Type
- AMD 990FX
- FX / Phenom II / Athlon II / Sempron 100 Series
- DDR3 2100(OC) / 1866 / 1600 / 1333 / 1066 / 800
Specs
Reviews (1)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the ASRock 990FX Extreme3
| Brand | ASRock |
|---|---|
| Model | 990FX Extreme3 |
| CPU Socket Type | AM3+ |
|---|---|
| CPU Type | FX / Phenom II / Athlon II / Sempron 100 Series |
| FSB | 2600 MHz |
| Chipset | AMD 990FX |
|---|---|
| South Bridge | AMD SB950 |
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 2100(OC) / 1866 / 1600 / 1333 / 1066 / 800 |
| Maximum Memory Supported | 32GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 3 (x16 , x16, x4) |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| Serial ATA (SATA) | 5 x SATA 6Gb/s |
|---|---|
| SATA RAID | 0/1/5/10 |
| Onboard Video Chipset | None |
|---|
| Audio Chipset | Realtek ALC892 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Broadcom BCM57781 |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x Optical S/PDIF Out / 1 x S/PDIF Coaxial Out / 2 x PS/2 / 2 x USB 3.1 Gen 1 / 6 x Audio Jacks / 6 x USB 2.0/1.1 |
|---|---|
| PS/2 | 2 |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 6 x USB 2.0 |
| eSATA | 1 x eSATA 6Gb/s |
| S/PDIF Out | 1 x Optical, 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|---|
| Other Connectors | 1 x IR header 1 x COM port header 1 x HDMI_SPDIF header 1 x Power LED header CPU/Chassis/Power FAN connector 24 pin ATX power connector 8 pin 12V power connector Front panel audio connector |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12" x 8.6" |
| Power Pin | 24 Pin |
| Features | ASRock DuraCap (2.5 x longer life time), 100% Japan-made high-quality Conductive Polymer Capacitors Supports AM3+ Processor, 8-Core CPU Supports Dual Channel DDR3 2100(OC) Supports AMD Quad CrossFireX , 3-Way CrossFireX and CrossFireX Supports NVIDIA Quad SLI and SLI 2 x USB 3.0, 5 x SATA3, 1 x eSATA3 Supports XFast USB, XFast LAN Technologies Supports On/Off Play Technology, Graphical UEFI BIOS, AXTU, APP Charger, SmartView, Turbo UCC 7.1 CH HD Audio with Content Protection, supports THX TruStudio Free Bundle : CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX Multimedia Suite, 1 x 3.5mm Audio Cable |
|---|
| First Listed on Newegg | August 05, 2013 |
|---|
