ASRock H61DE/S3 LGA 1155 Intel H61 HDMI ATX Intel Motherboard
- Intel H61
- Core i7 / i5 / i3 (LGA1155)
- DDR3 1333/1066
Specs
Reviews (5)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the ASRock H61DE/S3
| Brand | ASRock |
|---|---|
| Model | H61DE/S3 |
| CPU Socket Type | LGA 1155 |
|---|---|
| CPU Type | Core i7 / i5 / i3 (LGA1155) |
| Chipset | Intel H61 |
|---|
| Onboard Video Chipset | Supported only by CPU with integrated graphic |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 1333/1066 |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| Serial ATA (SATA) | 2 x SATA 6Gb/s |
|---|
| Audio Chipset | Realtek ALC887 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Atheros AR8151 |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x HDMI / 1 x Optical S/PDIF Out / 1 x PS/2 Keyboard/Mouse Combo / 6 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 |
| Video Ports | D-Sub + DVI |
| HDMI | 1 x HDMI |
| USB 1.1/2.0 | 6 x USB 2.0 |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 5 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12" x 8.6" |
| Power Pin | 24 Pin |
| Features | 100% All Solid Capacitor design Supports Intel K-Series CPU Supports Dual Channel DDR3 1333 Supports Intel HD Graphics 2000/3000 Multi VGA Output options: D-Sub, DVI-D and HDMI Supports XFast USB, AXTU, Graphical UEFI, Instant Boot, Instant Flash, APP Charger, SmartView Combo Cooler Option (C.C.O.) |
|---|
| Date First Available | June 20, 2011 |
|---|
