Brand | ASRock |
---|---|
Model | N68PV-GS |
CPU Socket Type | AM2+/AM2 |
---|---|
CPU Type | Phenom FX / Phenom / Athlon 64 FX / Athlon 64 X2 |
FSB | 1000 MHz |
Chipset | NVIDIA GeForce 7050 |
---|
Number of Memory Slots | 2x240pin |
---|---|
Memory Standard | DDR2 1066 with AM2+ CPU DDR2 800/667/533 with AM2 CPU |
Maximum Memory Supported | 8GB |
Channel Supported | Dual Channel |
PCI Express x16 | 1 x PCI Express x16 |
---|---|
PCI Express x1 | 1 x PCI Express x1 |
PCI Slots | 2 x PCI Slots |
PATA | 1 x ATA100 2 Dev. Max |
---|---|
SATA 3Gb/s | 4 x SATA 3Gb/s |
SATA RAID | 0/1/0+1/5/JBOD |
Onboard Video Chipset | NVIDIA GeForce 7050 |
---|
Audio Chipset | Realtek ALC662 |
---|---|
Audio Channels | 6 Channels |
LAN Chipset | Realtek 8211CL |
---|---|
Max LAN Speed | 10/100/1000Mbps |
PS/2 | 2 |
---|---|
Video Ports | D-Sub + DVI |
USB 1.1/2.0 | 4 x USB 2.0 |
Audio Ports | 3 Ports |
Onboard USB | 2 x USB 2.0 headers support 4 x USB 2.0 ports |
---|
Form Factor | Micro ATX |
---|---|
Dimensions (W x L) | 9.6" x 7.2" |
Power Pin | 24 Pin |
Windows Vista | Certified for Windows Vista |
---|
Date First Available | December 10, 2008 |
---|
