ASUS A7V8X 462(A) VIA KT400 ATX AMD Motherboard

(46) Write a Review
  • VIA KT400
  • Athlon XP / Athlon / Duron
  • DDR 400 (PC 3200) Note: PC3200 Max. to 2 banks only; PC2700 Max. to 4 banks only
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Specs
Reviews (46)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the ASUS A7V8X

Model
Brand ASUS
Model A7V8X
Supported CPU
CPU Socket Type 462(A)
CPU Type Athlon XP / Athlon / Duron
FSB 333/266 MHz
Chipsets
Chipset VIA KT400
South Bridge VIA VT8235
Memory
Number of Memory Slots 3x184pin
Memory Standard DDR 400 (PC 3200)
Note: PC3200 Max. to 2 banks only; PC2700 Max. to 4 banks only
Maximum Memory Supported 3GB
Expansion Slots
AGP Slots 1 x AGP 4X / 8X
PCI Express x16 None
PCI Slots 6 x PCI (one shared with optional ASUS proprietary wireless slot)
Storage Devices
PATA 3 x ATA100 6 Dev Max.
PATA RAID 0/1
SATA RAID 0/1
Additional RAID Controller Promise
Onboard Video
Onboard Video Chipset None
Onboard Audio
Audio Chipset AC97 Codec
Audio Channels 6 Channels
Onboard LAN
Max LAN Speed 100Mbps
Rear Panel Ports
Back I/O Ports 1 x LPT (Parallel Port) / 2 x COM (Serial Port) / 2 x PS/2 / 3 x Audio Jacks / 4 x USB 2.0/1.1
PS/2 2
COM 2
LPT 1
USB 1.1/2.0 4 x USB 2.0
Audio Ports 3 Ports
Internal I/O Connectors
Onboard USB 2 x USB 2.0
Onboard 1394 2 x 1394a
Physical Spec
Form Factor ATX
Dimensions (W x L) 12.0" x 9.6"
Power Pin 20 Pin
Additional Information
First Listed on Newegg October 04, 2002
