ASUS CROSSHAIR V FORMULA-R AM3+ AMD 990FX USB 3.0 ATX AMD Gaming Motherboard with 3-Way SLI/CrossFireX Support and UEFI BIOS

REFURBISHED

Be the first to review this product...

AMD 990FX
FX / Phenom II / Athlon II / Sempron 100 Series
DDR3 2133(O.C.)/2000(O.C.)/1800(O.C.)/1600/1333/1066

🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Model
Brand	ASUS
Model	CROSSHAIR V FORMULA-R

Supported CPU
CPU Socket Type	AM3+
CPU Type	FX / Phenom II / Athlon II / Sempron 100 Series

Chipsets
Chipset	AMD 990FX
South Bridge	AMD SB950

Memory
Number of Memory Slots	4x240pin
Memory Standard	DDR3 2133(O.C.)/2000(O.C.)/1800(O.C.)/1600/1333/1066
Maximum Memory Supported	32GB
Channel Supported	Dual Channel

Expansion Slots
PCI Express 2.0 x16	3 (dual x16 or x16, x8, x8) 1 (x4 mode)
PCI Express x1	1 x PCI Express x1
PCI Slots	1 x PCI Slot

Storage Devices
Serial ATA (SATA)	7 x SATA 6Gb/s
SATA RAID	6 x SATA 6Gb/s port(s), red support Raid 0, 1, 5, 10 by AMD SB950

Onboard Video
Onboard Video Chipset	None

Onboard Audio
Audio Chipset	SupremeFX X-Fi 2
Audio Channels	8 Channels

Onboard LAN
Max LAN Speed	1Gbps

Rear Panel Ports
Back I/O Ports	1 x Optical S/PDIF Out / 1 x PS/2 / 4 x USB 3.1 Gen 1 / 6 x Audio Jacks / 8 x USB 2.0/1.1
PS/2	1 x PS/2 keyboard/mouse port
USB 3.0	4 x USB 3.0
USB 1.1/2.0	8 x USB 2.0 (white port can be switched to ROG Connect)
eSATA	1 x eSATA 6Gb/s
S/PDIF Out	1 x Optical
Audio Ports	6 Ports

Internal I/O Connectors
Onboard USB	2 x USB 3.0 + 4 x USB 2.0

Physical Spec
Form Factor	ATX
Dimensions (W x L)	12.0" x 9.6"
Power Pin	24 Pin

Features
Features	3-Way NVIDIA SLI / AMD CrossFireX Technology Extreme Engine Digi+ - Powerful combination of analog and digital design elements SupremeFX X-Fi 2 - Play with ultra-real cinematic in-game surround sound! GameFirst - Creates the speed you need to PWN! Intel Gigabit LAN - Experience the fast network connectivity! UEFI BIOS - Flexible & Easy BIOS Interface
