Will this product be compatible with http://www.newegg.com/Product/Product.aspx?Item=N82E16820231666 ? Does the O.C. next to the DDR3 stand for overclock or is it still standard to use those types?

I have found this Motherboard to be compatible with nothing but the energy that it consumes. My Mobo will not boot into the bios and after several unproductive service contacts with ASUS they decided that it needs to be repaired. Newegg is weaseling out and will not correspond with me and ASUS hasn't provided me the info to return it there either. Make your own decision.

Out of stock

This item is currently out of stock and it may or may not be restocked.

Out of Stock

Add to wish list

Sold by Newegg

Shipped by Newegg

More Resources

MB ASUS|F2A85-M/CSM A85 FM2 R Memory Compatibility

MB ASUS|F2A85-M/CSM A85 FM2 R CPU Compatibility

Main image of ASUS F2A85-M/CSM FM2 AMD A85X (Hudson D4) USB 3.0 HDMI Micro ATX AMD Motherboard

Alt view image 2 of 5 - ASUS F2A85-M/CSM FM2 AMD A85X (Hudson D4) USB 3.0 HDMI Micro ATX AMD Motherboard

Alt view image 3 of 5 - ASUS F2A85-M/CSM FM2 AMD A85X (Hudson D4) USB 3.0 HDMI Micro ATX AMD Motherboard

Alt view image 4 of 5 - ASUS F2A85-M/CSM FM2 AMD A85X (Hudson D4) USB 3.0 HDMI Micro ATX AMD Motherboard

Alt view image 5 of 5 - ASUS F2A85-M/CSM FM2 AMD A85X (Hudson D4) USB 3.0 HDMI Micro ATX AMD Motherboard

Shop All ASUS Products

ASUS F2A85-M/CSM FM2 AMD A85X (Hudson D4) USB 3.0 HDMI Micro ATX AMD Motherboard

(22) Write a Review

AMD A85X (Hudson D4)
APU (FM2 Socket)
DDR3 2400(OC)/2250(OC)

🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available

Overview

Specs

Reviews (22)

Any questions? Our AI beta will help you find out quickly.

Try me now

Model
Brand	ASUS
Model	F2A85-M/CSM

Supported CPU
CPU Socket Type	FM2
CPU Type	APU (FM2 Socket)

Chipsets
Chipset	AMD A85X (Hudson D4)

Memory
Number of Memory Slots	4x240pin
Memory Standard	DDR3 2400(O.C.)/2250(O.C.)/2200(O.C.)/2133(O.C.)/1866/1600/1333/1066
Maximum Memory Supported	64GB
Channel Supported	Dual Channel

Expansion Slots
PCI Express 2.0 x16	2 (x16/x4)
PCI Express x1	1 x PCI Express x1
PCI Slots	1 x PCI Slot

Storage Devices
Serial ATA (SATA)	7 x SATA 6Gb/s
SATA RAID	0/1/5/10/JBOD

Onboard Video
Onboard Video Chipset	None

Onboard Audio
Audio Chipset	Realtek ALC887
Audio Channels	8 Channels

Onboard LAN
LAN Chipset	Realtek 8111F
Max LAN Speed	1Gbps

Rear Panel Ports
Back I/O Ports	1 x D-Sub / 1 x DVI / 1 x HDMI / 1 x Optical S/PDIF Out / 1 x PS/2 / 2 x USB 3.1 Gen 1 / 4 x USB 2.0/1.1 / 6 x Audio Jacks
PS/2	1 x PS/2 keyboard/mouse port
Video Ports	D-Sub + DVI
HDMI	1 x HDMI
USB 3.0	2 x USB 3.0
USB 1.1/2.0	4 x USB 2.0
eSATA	1 x eSATA 6Gb/s
S/PDIF Out	1 x Optical
Audio Ports	6 Ports

Internal I/O Connectors
Onboard USB	2 x USB 3.0 + 6 x USB 2.0
Other Connectors	1 x TPM connector(s) 1 x COM port(s) connector(s) 1 x CPU Fan connector(s) (4 -pin) 1 x Chassis Fan connector(s) (4 -pin) 1 x Power Fan connector(s) (3 -pin) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 1 x MemOK! button(s) 1 x GPU Boost switch(es)

Physical Spec
Form Factor	Micro ATX
Dimensions (W x L)	9.6" x 9.6"
Power Pin	24 Pin

Features
Features	DIGI+VRM Power Control Remote GO! - One-stop PC Remote Control and Home Entertainment USB 3.0 Boost - Accelerated USB 3.0 Data Transfer Rates with ASUS USB 3.0 Boost Technology Network iControl - Real-time Network Bandwidth Control MemOK! - Any Memory is A-OK! Windows 8 Ready - Assured Compatibility

Additional Information
First Listed on Newegg	October 09, 2012

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 3 years
Limited Warranty period (labor): 3 years
Read full details

Return Policies

Return for refund within: 30 days

Return for replacement within: 30 days

This item is covered by Newegg.com's 30-Day Return Policy. Read full return policy for details.
