Question 1

Does this work with the maximus XI formula?

Accepted Answer

Yes, this should work with the Maximus XI formaila mother board provided your CPU has the available PCI lanes. https://www.newegg.com/Product/Product.aspx?Item=2HK-0012-00527&turntoqid=TkAGY08YZQ&turntosuid=SEYGbU4Z&sourceId=1&turntoQuestionId=4029777&turntoEmailType=question&iqrlId=65678603&turntosku=2HK-0012-00527&turntoflow=answer#turntodone

Question 2

Will this card work on Thread Ripper Motherboards?

Accepted Answer

I have one .Run it in combo with the three onboard in raid 0 . close to 6000 mbps read and write. I have the GIGABYTE X399 AORUS Gaming 7 sTR4 AMD X399 ATX 3*M.2 4-Way SLI AMD Motherboard

Question 3

Does this card still support 4 m.2 drives in a PCI Express x8 Slot or will this limit the card to two drives? I am planning to put it in the fourth slot of my asus rampage vi extreme mb (x16, x0, x16, x8). I have graphics cards in the x16 slots.

Accepted Answer

If you place this in the x8 slot on your Asus R6E, it will only read the nVME drives located in slot 1 and 2. It will not read/connect anything in slots 3 and 4. I had issues detecting all four drives in the x16 slot on my R6E so be wary that it's not a fully fleshed out product. Currently using 2 nvme drives on the Asus Hyper x16 card + 1 nvme drive in the dimm.2.1 slot (as the dimm.2.2 slot runs off PCH not CPU)  + 1 nvme drive in an Asus Hyper x4 expansion card in order to achieve a CPU managed RAID 0 with 4 nvme drives. Hope that helps.

Question 4

Is there RAID 1 options with this ?  If there is something else that's needed what is it ?

Accepted Answer

The card comes with no software.  Assuming you don't have a Asujs MB per their requirement, And if you're lucky enough to have a recent server MB, you can set your PCIe x16 slot to 4x4x4x4 - usually server motherboards have this option - if they are fairly recent, then it will show up as 4 different drives.   With no ASUS MB that meets their specs, if you can't set your PCIex16 slot to 4x4x4x4 it will just show the first drive.

I was able to set my supermicro MB to 4x4x4x4 on a PCIe x16 slot, and everything showed up and worked great.  Another cheaper server MB with a bios last updated in 2015 didn't have this option.

Question 5

ok i have a asus z170 pro gaming aura and i7-6700k CPU and 32gb ram will this work with 1 Samsung 512GB M.2 PCI Express Gen3 x4,Solid state drive PM951 Model: MZVLV512HCJH-00000SSD,PM951and SSD 970 EVO NVMe M.2 2TB Model:  MZ-V7E2T0BW ?

Accepted Answer

Hello,

The compatible motherboards list is:

ROG RAMPAGE VI EXTREME
ROG RAMPAGE VI APEX
ROG STRIX X299-XE GAMING
ROG STRIX X299-E GAMING
PRIME X299-DELUXE
PRIME X299-A
TUF X299 MARK 1
TUF X299 MARK 2

Question 6

Can this card be used in a raid 10 config. with 4 drives it would be in a ROG Maximus XI HERO with an I9-9900K?

Accepted Answer

Yes, this card supports Intel VROC ready and NVMe RAID, which includes RAID configurations like RAID 10 with four NVMe M.2 drives.

Question 7

is this listing selling the HYPER M.2 X16 CARD V2 (Version 2) or The original version? Need it to be able to support AMD Threadripper.

Accepted Answer

Specifically to Your Question - You'll have to Contact the Seller and Ask. With that said, Yes, works on AMD Threadripper! In Bios / UEFI, under Chipset, set Your PCI x16 Slot to X4X4X4X4 - PCIe Bifurcation. Cheers!

Question 8

Are there any AM4 motherboards that this can work on?  I see that it just requires pcie bifurcation.  Plan on putting this card in slot 1 and using x8 PCIe slot for graphics.

Accepted Answer

No - You need a different card with the Bifurcation Switch Built-In - 2 Options:
1.) High Point SSD7101A-1 4X Dedicated 32Gbps M.2 Ports to PCIe 3.0 x16 RAID Controller
2.) High Point SSD7102 Bootable 4X M.2 NVMe RAID Controller
Hope that helps!

Question 9

Does this card work with SATA (M2) drive, too?

Accepted Answer

No - NVMe Only!

Question 10

Hi. Are  ASUS ROG MAXIMUS VIII HERO/Whetstone motherboard supported?

Accepted Answer

Your Motherboard has to support PCIe Bifurcation - Meaning - The ability, in the Bios / UEFI firmware to change a X16 Slot to X4X4X4X4. Otherwise, You need a Card that has the PCIe Bifurcation Switch Built-In. Hope that helps!
