Brand | ASUS |
---|---|
Model | P4T533-C |
CPU Socket Type | Socket 478 |
---|---|
CPU Type | Pentium 4 / Celeron |
FSB | 533/400 MHz |
Chipset | Intel 850E |
---|---|
South Bridge | Intel ICH2 |
Onboard Video Chipset | None |
---|
Maximum Memory Supported | 4x RDRAM Slots 1066 MHz Rambus architecture provide 4.2GB/s bandwidth. The maximum memory capacity is 2GB Caution : The rambus memory must be installed in pairs on the motherboard |
---|---|
Channel Supported | Dual Channel |
AGP Slots | 1 x AGP 2X / 4X |
---|---|
PCI Slots | 5 x PCI Slots |
PATA | 2 x ATA100 4 Dev. Max |
---|
Audio Chipset | AC97 Codec |
---|---|
Audio Channels | 6 Channels |
Max LAN Speed | 100Mbps |
---|
Back I/O Ports | 2 x PS/2 / 4 x USB 2.0/1.1 |
---|---|
PS/2 | 2 |
COM | 2 |
LPT | 1 |
USB 1.1/2.0 | 4 x USB 2.0 |
Audio Ports | 3 Ports |
Onboard USB | 2 x USB 2.0 |
---|
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12.0" x 9.6" |
Power Pin | 20 Pin |
First Listed on Newegg | July 29, 2002 |
---|
