Learn more about the ASUS P5K SE
Model
Brand
ASUS
Model
P5K SE
Supported CPU
CPU Socket Type
LGA 775
CPU Type
Core 2 Quad / Core 2 Extreme / Core 2 Duo
FSB
1333/1066 MHz
Chipsets
Chipset
Intel P35
South Bridge
Intel ICH9
Onboard Video
Onboard Video Chipset
None
Memory
Number of Memory Slots
4x240pin
Memory Standard
DDR2 1066
Maximum Memory Supported
8GB
Channel Supported
Dual Channel
Expansion Slots
PCI Express x16
1 x PCI Express x16
PCI Express x1
3 x PCI Express x1
PCI Slots
2 x PCI Slots
Storage Devices
PATA
1 x ATA100 2 Dev. Max
Onboard Audio
Audio Chipset
Realtek ALC883
Audio Channels
8 Channels
Onboard LAN
Max LAN Speed
1Gbps
Rear Panel Ports
PS/2
1
USB 1.1/2.0
6 x USB 2.0
eSATA
1 x eSATA 3Gb/s
S/PDIF Out
1 x Coaxial
Audio Ports
6 Ports
Physical Spec
Form Factor
ATX
Dimensions (W x L)
12.0" x 7.6"
Features
Features
The chipset officially supports the memory frequency up to DDR2 800MHz. Tuned by ASUS Super Memspeed Technology, this motherboard natively supports up to DDR2 1066MHz
