ASUS PC-DL Deluxe ATX Server Motherboard Dual 603/604 Intel 875P

OPEN BOX Product Type
  • Dual 603/604
  • Intel 875P
  • 4 x 184Pin
Please note that this product is non-returnable and non-refundable.
Specs
avatar

Any questions? Our AI beta will help you find out quickly.

Learn more about the ASUS PC-DL Deluxe

Model
Brand ASUS
Model PC-DL Deluxe
Supported CPU
CPU Socket Type Dual 603/604
CPU Type Dual Intel Xeon
System Bus 533/400 MHz
Chipsets
North Bridge Intel 875P
South Bridge Intel ICH5R
Memory
Number of DDR Slots 4 x 184Pin
DDR Standard DDR 333 (PC 2700)
Maximum Memory Supported 4GB
Channel Supported Dual Channel
Expansion Slots
AGP Slots 1 x AGP 4X / 8X
PCI Slots 5 x PCI Slots
Storage Devices
PATA 2 x ATA 100 4 Dev. Max
Additional PATA 1 x ATA 133 2 Dev. Max
SATA 2 x SATA 1.5Gb/s
SATA RAID 0/1
Additional SATA 2 x SATA 1.5Gb/s
Additional SATA RAID 0/1/0+1
Additional RAID Controller Promise PDC20378
Onboard Video
Onboard Video Chipset None
Onboard Audio
Audio Chipset AD1985
Audio Channels 6 Channels
Onboard LAN
LAN Chipset Intel 82547EI
LAN Speed 10/100/1000Mbps
Max LAN Speed 1Gbps
Rear Panel Ports
PS/2 2
COM 2
LPT 1
USB 1.1/2.0 4 x USB 2.0
IEEE 1394 1 x IEEE 1394a
Audio Ports 3 Ports
Onboard Ports
Onboard USB 4 x USB 2.0
Onboard 1394 1 x 1394a
Dimensions
Form Factor ATX
Dimensions (W x L) 12" x 9.6"
Additional Information
First Listed on Newegg December 31, 2003
