Learn more about the ASUS QG-U1080
Model| Brand | ASUS |
|---|
| Model | QG-U1080 |
|---|
| Part Number | 90IG0A00-MA1B0T |
|---|
Format & Standards| Format | Desktop |
|---|
| Standards | IEEE802.3u 100BASE-TX IEEE802.3ab 1000BASE-T IEEE802.3bz 2.5G BASE-T IEEE 802.3-2012, IEEE 10GBASE-KR (10.3125 Gbps) IEEE802.3az EEE IEEE802.3x Flow control |
|---|
| Network Management Type | Unmanaged |
|---|
Ports & Interface| Primary Ports | 2 x SFP+ / 8 x RJ45 |
|---|
| Primary Port Speed | 2.5 Gbps + 10 Gbps |
|---|
| Primary Port Type | 8 x 2.5G RJ45 + 2 x 10G SFP+ |
|---|
Data Transmission| MAC Address Table | 16K |
|---|
| Jumbo Frames | 10KB |
|---|
| Packet Forwarding Rate | 18.6Mpps (64-byte) |
|---|
| Buffer Memory | 8Mbits |
|---|
Details| PoE | Yes |
|---|
| LEDs | Power LED Off: The switch is powered off or fails. Green On: The switch is powered on. Blinking: Loop detected.
Port 1-8 LED Off: Devices are disconnected or the link has failed. Green On: 2.5Gbps connection Amber On: 10/100/1000Mbps connection Blinking: Devices are connected and data is transmitting or receiving. Blinking rapidly: Loop detected.
SFP+ Port 9-10 LED Off: Devices are disconnected or the link has failed. Green On: 10Gbps connection Amber On: 1Gbps connection Blinking: Devices are connected and data is transmitting or receiving. Blinking rapidly: Loop detected. |
|---|
Power Supply| Power | External Power Adapter Output: 12V/1A |
|---|
Dimensions & Weight| Dimensions | 7.6" x 3.31" x 1.02" |
|---|
| Weight | 0.93 lb. |
|---|
Environmental| Temperature | Operating Temperature: 0 ~ 40°C Storage Temperature: -40 ~ 70°C |
|---|
| Humidity | Operating Humidity: 10% ~ 90% RH (non-condensing) Storage Humidity: 5% ~ 90% RH (non-condensing) |
|---|
Packaging| Package Contents | ASUS QG-U1080 Switch Power Adapter Quick Start Guide Warranty Card |
|---|
Additional Information| First Listed on Newegg | October 10, 2025 |
|---|
