Question 1

Does it come with a Wi-Fi antenna? Shows a antenna in the picture but not in the accessory list.

Accepted Answer

It does come with the Wi-Fi antenna. Just be sure you are ordering the Maximus X Hero (Wi-Fi AC).

Question 2

Im looking to building a pc with a i7 7700k and a ddr5 nvidia graphics card, would this motherboard be a good one to support those?

Accepted Answer

No, you cannot use a Kaby lake CPU i.e. intel 7th Gen CPU on a z370 series chipset motherboard such as this one. You need z170 or z270 for kaby lake or z370 for coffee lake i.e intel 8thgen CPU's. As for your GPU, the generation of GDDR memory doesn't really matter, any PCI Express based graphics card will work.

Question 3

Will this board support my current 7th Gen i7 6700k CPU?

Accepted Answer

No. This board supports the new 8th generation 8000 series chips at the moment. The chipset is what you need to do research on. This board is Z370 intel chipset you need the z270. Look these up on Google.

Question 4

Will this board accept my Geforce 980 GTX?  it appears the heatsink in the front might block it.

Accepted Answer

The chipset heatsink is shorter than the PCI-E sockets. It will not block your GPU.

Question 5

I got my motherboard today. Does it comes with plastic wrap around the box I feel like I got open box ?

Accepted Answer

No, the box is not covered in cellophane or otherwise sealed (at a store, it would be possible to open the box and see the motherboard).

Question 6

What kind of power supply should i use for a I7 8700k and gtx 1080 and this Mobo?

Accepted Answer

GeForce GTX 1070 / 1080 - On your average system the card requires you to have a 600 Watts power supply unit.

GeForce GTX 1070 / 1080 SLI - On your average system the cards require you to have a 850~900 Watts power supply unit.

If you want to overclock everything, then you will probably want something a little bigger.  I'd personally lean towards somewhere in the neighborhood of 800 just to be safe if you are only running one card.

Question 7

Does it come with a mousepad?

Accepted Answer

No, this model does not come with a mouse-pad.

Question 8

Does the SLI bridge included with this come as a 2 slot SLI bridge or a 3 slot SLI bridge?

Accepted Answer

This model includes SLI bridge is a 2 slot. (60mm).

Question 9

Does this board come with WIFI built in? if not what is a good WIFI card you would recommend? Will the chip support my i7 8700K Coffee lake processor and my GTX 1060?

Accepted Answer

I understand this can all be confusing, but I highly recommend understanding what style motherboards fit your selected chip.

This motherboard does have an internal WIC with external intennas, so you do not need a wireless card. Remember though a hardwire is always recommended over wireless to reduce latency. Also this board, and any Z370 style will support Coffee Lake processors. If you’re not going to be using the advanced over clocking features and/or NVMe slots, you could get a cheaper motherboard.

I also (after looking at your handle) would like to remind you that a 8700k is not needed for gaming. You would see very little benefit over a 8600k if you’re buying strictly for gaming. You could use these extra funds to buy a stronger GPU which would net you better gaming performance.

Question 10

are these m.2 slots NVME?

Accepted Answer

No, these seam to be PCI Express 3.0/2.0 bandwidth not NVMe

Brand	ASUS
Series	ROG
Model	Maximus X Hero (Wi-Fi AC)

CPU Socket Type	LGA 1151 (300 Series)
CPU Type	Intel Socket 1151 9th/8th Gen Intel Core, Pentium Gold and Celeron Processors * Not backward compatible with older generation of LGA 1151 CPUs * Refer to www.asus.com for CPU support list
Supported CPU Technologies	Supports Intel Turbo Boost Technology 2.0* * Intel Turbo Boost Technology 2.0 support depends on the CPU types

Number of Memory Slots	4x288pin (DDR4)
Memory Standard	DDR4 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2800(O.C.)/ 2666/ 2400/ 2133 * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Maximum Memory Supported	64GB
Channel Supported	Dual Channel

PCI Express 3.0 x16	2 x PCIe 3.0 x16 (x16 or dual x8 or x8/x4/x4) 1 x PCIe 3.0 x16 (x4 mode) * * The PCIe x4_3 slot shares bandwidth with PCIex1_3. The PCIe x4_3 runs x2 mode by default.
PCI Express x1	3 x PCIe 3.0/2.0 x1

Serial ATA (SATA)	6 x SATA 6Gb/s
M.2	1 x M.2_1 Socket 3 with M Key, type 2242/2260/2280 (supports PCIE 3.0 x4 and SATA modes)* 1 x M.2_2 Socket 3 with M Key, type 2242/2260/2280 (supports PCIE 3.0 x4 mode)** * When the M.2_1 Socket 3 is operating in SATA mode, SATA port 1 will be disabled. ** When the M.2_2 Socket 3 is operating in PCIEX4 mode, SATA port 5. 6 will be disabled.
SATA RAID	0/1/5/10

Meet Your Seller

ASUS ROG Maximus X Hero (Wi-Fi AC) LGA 1151 (300 Series) Intel Z370 ATX Intel Motherboard

Used - Very Good

Learn more about the ASUS Maximus X Hero (Wi-Fi AC)

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Audio Chipset	ROG SupremeFX High Definition Audio CODEC S1220
Audio Channels	8 Channels

LAN Chipset	Intel I219-V
Max LAN Speed	1Gbps
Wireless LAN	Wi-Fi 802.11 a/b/g/n/ac Supports dual band frequency 2.4/5 GHz Supports MU-MIMO
Bluetooth	Bluetooth V4.2

Onboard USB	1 x USB 3.1 Gen 2 front panel connector 1 x USB 3.1 Gen 1 (up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Other Connectors	1 x Aura Addressable Strip Header(s) 2 x Aura RGB Strip Headers 1 x TPM connector(s) 1 x CPU Fan connector(s) (1 x 4-pin) 1 x CPU OPT Fan connector(s) (1 x 4-pin) 3 x Chassis Fan connector(s) (3 x 4-pin) 1 x AIO_PUMP connector (1 x 4-pin) 1 x H_AMP fan connector 1 x W_PUMP+ connector (1 x 4-pin) 1 x Front panel audio connector(s) (AAFP) 1 x MemOK! button(s) 1 x Slow Mode switch(es) 1 x Reset button(s) 1 x LN2 Mode jumper(s) 1 x Safe Boot button 1 x ReTry button 1 x System panel connector 3 x 3D Mount screw port(s) 1 x EXT_Fan header 1 x W_IN header 1 x W_OUT header 1 x W_FLOW header 1 x Thermal sensor connector 1 x Start button

Form Factor	ATX
LED Lighting	RGB
Dimensions (W x L)	12.0" x 9.6"
Power Pin	1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s)

Item#: 9SIAWFGKD89693
