Learn more about the ASUS RS100-E10-PI2
Model
Brand
ASUS
Model
RS100-E10-PI2
CPU Supported
CPU Type
Intel Xeon E Processors
CPU Socket
LGA 1151
Chipset
North Bridge
Intel C242
Memory Supported
Max Memory Supported
Maximum up to 64GB UDIMM
Memory Type Supported
DDR4 2666 / 2400 UDIMM non ECC and with ECC
Graphics
GPU/VPU
Aspeed AST2500 with 32MB VRAM
Expansion Slots
PCI-X
Total PCI/PCI-X/PCI-E/PIKE Slots: 1 1 x PCI-E x16 (x16 Gen3 Link)
Communications
Number of LAN
4 x Intel I210AT + 1 x Mgmt LAN
Panel Ports
VGA
1 x VGA port
Rear USB
2 x USB 3.1 ports 2 x USB 3.0 ports
RJ45
4 x RJ-45 ports 1 x RJ-45 ports (One for ASMB9-iKVM) (Optional)
Power Supply
Max. Power
Single 250W 80 PLUS Bronze Power Supply Rating: 100-240V AC,4A ,50-60 Hz, Class I Single 350W 80 PLUS Gold Power Supply Rating: 100-240V AC, 6A-3A, 50-60 Hz, Class I
Features
Features
Generation: E10
Storage: SATA Controller: Intel C242 Chipset 2 x Internal 3.5" HDD 2 x M.2 connector (2242/2260/2280/22110) both SATA & PCIe mode Intel Rapid Storage Technology Enterprise(RSTe) (For Linux / Windows) (Support Software RAID 0, 1 )
HDD Bays: with ODD, up to 2 x 3.5" disk bay or option 1 x 3.5"+ 2 x 2.5" disk bay support without ODD, up to 2 x 3.5" disk bay or option 1 x 3.5"+ 4 x 2.5" disk bay support
