Learn more about the ASUS TUF-RTX3060-12G-V2-GAMING
Model
Brand
ASUS
Series
TUF Gaming
Model
TUF-RTX3060-12G-V2-GAMING
Interface
Interface
PCI Express 4.0
Chipset
Chipset Manufacturer
NVIDIA
GPU Series
NVIDIA GeForce RTX 30 Series
GPU
GeForce RTX 3060
Architecture
Ampere
Boost Clock
OC Mode - 1807 MHz Gaming Mode - 1777 MHz
CUDA Cores
3584 Cores
Memory
Effective Memory Clock
15 Gbps
Memory Size
12GB
Memory Interface
192-Bit
Memory Type
GDDR6
3D API
DirectX
DirectX 12 Ultimate
OpenGL
OpenGL 4.6
Ports
Multi-Monitor Support
4
HDMI
2 x HDMI 2.1
DisplayPort
3 x DisplayPort 1.4a
Details
Max Resolution
7680 x 4320
SLI Support
No
Virtual Reality Ready
Yes
Cooler
Triple Fans
Thermal Design Power
170W
Recommended PSU Wattage
750W
Power Connector
1 x 8-pin
HDCP Ready
2.3
Features
Features
NVIDIA Ampere Streaming Multiprocessors: The building blocks for the world's fastest, most efficient GPUs, the all-new Ampere SM brings 2X the FP32 throughput and improved power efficiency.
2nd Generation RT Cores: Experience 2X the throughput of 1st gen RT Cores, plus concurrent RT and shading for a whole new level of ray tracing performance.
3rd Generation Tensor Cores: Get up to 2X the throughput with structural sparsity and advanced AI algorithms such as DLSS. These cores deliver a massive boost in game performance and all-new AI capabilities.
Axial-tech fan design has been newly tuned with a reversed central fan direction for less turbulence.
Dual ball fan bearings can last up to twice as long as sleeve bearing designs.
An all-aluminum shroud and metal backplate enhance durability.
GPU Tweak II provides intuitive performance tweaking, thermal controls, and system monitoring.
Form Factor & Dimensions
Max GPU Length
301 mm
Card Dimensions (L x H)
11.81" x 5.63"
Slot Width
2.7 Slot
Packaging
Package Contents
Accessories: 1 x TUF certificate of Reliability 1 x Collection card 1 x Speedsetup Manual
Additional Information
First Listed on Newegg
April 21, 2025
