Brand | ATI |
---|---|
Model | 100-435703 |
Interface | PCI Express x16 |
---|
Chipset Manufacturer | AMD |
---|---|
GPU | Radeon X1800XL |
Core Clock | 500 MHz |
PixelPipelines | 16 |
Effective Memory Clock | 1000 MHz |
---|---|
Memory Size | 256MB |
Memory Interface | 256-Bit |
Memory Type | GDDR3 |
DirectX | DirectX 9 |
---|---|
OpenGL | OpenGL 2.0 |
DVI | 2 x DVI |
---|---|
TV-Out | HDTV / S-Video / Composite Out |
VIVO | Yes |
Tuner | None |
---|---|
RAMDAC | 400MHz |
Max Resolution | 2560x1600 |
Cooler | With Fan |
Operating Systems Supported | Windows XP/XP x64/MCE 2005 |
System Requirements | PCI Express based PC is required with one x16 lane graphics slot available on the motherboard. Connection to the system power supply is required (Adapter Included) 450-Watt power supply or greater recommended (assumes fully loaded system) 512MB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive and decoder software (not included) |
Features | 90nm process technology Ultra-threaded Shader Model 3.0 architecture Avivo Video and Display Technology 512-bit Ring-Bus memory controller 8 channel 256-bit memory interface DirectX 9.0 and OpenGL 2.0 support 256MB GDDR3 memory Two dual link DVI outputs Video-in/Video-out CrossFire Ready |
---|
Package Contents | HDTV Cable S-Video Cable Composite Cable VIVO Cable Power Cable 2 x DVI to VGA Adapter Drivers CD Manual |
---|
Date First Available | October 07, 2005 |
---|
