ATLONA HDMI (1.3) Audio De-Embedder with 3D Support AT-HD570

Be the first to review this product...

De-embed Audio (HDMI 1.3 or Lower)
Multi-channel Analog / Optical Outputs
Supports Uncompressed LPCM 7.1/5.1
Supports Dolby Digital / LPCM / DTS
Dolby True / DTS HD Master Audio Pass

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

3D Capable
HDCP Compliant
Support CEC bypass
Supports digital video formats in Deep Color Mode from 25MHz to 6.75GHz for 36 bits
Supports high definition input up to 1080p

Model
Brand	ATLONA
Model	AT-HD570

Power
Power Supply	5V/2.6A DC (110/220v)

Specification
Specification	Input port: HDMI Female (type A) Output port: HDMI Female (Type A); Optical (TosLink); 4 x 3.5mm Outs for Multi-Channel Audio HDMI input/output audio format: LPCM 7.1, 5.1, 2ch and Bit stream Dolby TrueHD, Dolby Digital Plus, Dolby Digital, DTS and DTS-HD Master Audio) Optical Output audio format: Dolby Digital, DTS 5.1, 2ch and LPCM 2 channels Multi-Channel audio format: LPCM 7.1/5.1/2 channels.

Feature
Feature	3D Capable Compliant with HDMI 1.3 or lower standards. HDCP Compliant Support CEC bypass Supports digital video formats in Deep Color Mode from 25MHz to 6.75GHz for 36 bits Supports high definition input up to 1080p Video Pass-through, no scaling Supports HDMI signal amplification and equalization with reclocking function Supports uncompressed digital audio formats LPCM 7.1, 5.1, 2ch through multi-channel analog outputs. Supports Dolby TrueHD and DTS-HD Master Audio pass through HDMI output Supports Dolby Digital, DTS 5.1, 2ch, and LPCM 2ch output through optical connection. Integrated HDMI Booster and Repeater.

Dimensions & Weight
Dimensions	5.8"D x 3.9"W x 0.98"H
Weight	2 lbs.

Package Contents
Package Content	1 x AT-HD570 Audio De-Embedder 1 x 5V DC power supply adaptor 1 x User Manual

Additional Information
First Listed on Newegg	April 14, 2011

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 1 year
Limited Warranty period (labor): 1 year
Read full details

Return Policies

Return for refund within: 30 days

Return for replacement within: 30 days

This item is covered by Newegg.com's 30-Day Return Policy. Read full return policy for details.
