Audio-Technica brings you the price/performance standard in side-address studio condenser microphone technology with the AT-2020. Ideal for project/home-studio applications, this mic features high SPL handling and wide dynamic range which provides unmatched versatility. Custom-engineered low-mass diaphragm provides extended frequency response and superior transient response. Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source. Pivoting, threaded stand mount attaches securely for easy and precise placement of the microphone. Specifications:Element: Condenser Signal to Noise Rati 74 dB, 1 kHz at 1 Pa Polar Pattern: Cardioid Dynamic Range (Typical) 124 dB, 1 kHz at Max. SPL Frequency Response: 20 - 20,000 Hz Phantom Power Requirements: 48V DC, 2 mA typical Open Circuit Sensitivity: -37 dB (14.1 mV) re 1V at 1 Pa Noise: 20 dB SPL Impedance: 100 ohms Weight: 12.1 oz (345 g) Maximum Input Sound Level: 144 dB SPL, 1 kHz at 1% T.H.D. Output Connector: Integral 3-pin XLRM-type ??WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
The Audio-Technica AT2020 microphone is ideal for project/home-studio applications as its affordable price and superior performance. The Audio-Technica AT2020 microphone features a custom-engineered low-mass diaphragm to provide extended frequency response and superior transient response. With rugged construction for durable performance, the Audio-Technica AT2020 microphone offers a wide dynamic range and handles high SPLs with ease.
High PerformanceThe Audio-Technica AT2020 microphone features high SPL handling and wide dynamic range provide unmatched versatility.
Low-Mass DiaphragmThe Audio-Technica AT2020 microphone features custom-engineered low-mass diaphragm to provide extended frequency response and superior transient response.
Cardioid Polar PatternThe Audio-Technica AT2020 microphone features cardioid polar pattern to reduce pickup of sounds from the sides and rear, improving isolation of desired sound source.
Learn more about the Audio-Technica AT2020
Model
Brand
Audio-Technica
Model
AT2020
Details
Type
Condenser Microphones
Specification
ELEMENT: Fixed-charge back plate, permanently polarized condenser POLAR PATTERN: Cardioid FREQUENCY RESPONSE: 20-20,000 Hz OPEN CIRCUIT SENSITIVITY: -37 dB (14.1 mV) re 1V at 1 Pa IMPEDANCE: 100 ohms MAXIMUM INPUT SOUND LEVEL: 144 dB SPL, 1 kHz at 1% T.H.D. NOISE: 20 dB SPL DYNAMIC RANGE (typical): 124 dB, 1 kHz at Max SPL SIGNAL-TO-NOISE RATIO: 74 dB, 1 kHz at 1 Pa PHANTOM POWER REQUIREMENTS: 48V DC, 2 mA typical OUTPUT CONNECTOR: Integral 3-pin XLRM-type
Features
Feature
The price/performance standard in side-address studio condenser microphone technology
Ideal for project/home-studio applications
High SPL handling and wide dynamic range provide unmatched versatility
Custom-engineered low-mass diaphragm provides extended frequency response and superior transient response
Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
Pivoting, threaded stand mount attaches securely for easy and precise placement of the microphone
Dimensions & Weight
Dimension
6.38" (Long) x 2.05" (maximum body diameter)
Weight
0.76 lb.
Package Contents
Package Contains
Stand mount for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; soft protective pouch
Additional Information
Date First Available
November 20, 2019
Customer Reviews of the Audio-Technica AT2020
There are no reviews yet.
Do you own this product?
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
Please contact the Seller directly for warranty information. Warranty information may also be found on the Manufacturer's website.
