AVMATRIX VS0601 4×SDI and 2×HDMI inputs Mini 6CH SDI/HDMI Multi-Format Video Switcher with GPIO Interface for Live Tally System

Model: VS0601

VS0601 is a miniature design metal housing 6-channel SDI/HDMI multi-format video switcher that allows video switching, audio mixing, and different transition effects. Inputs signal is auto-detected while for PGM output can be scaled, which can be compatible with more different equipment and more flexible. With cost effective price, it will be your perfect choice for various events production applications etc.
Multi-format 6 channel Mini video switcher
- Compact format portable for taking to everywhere
- Multiformat support on input signals
- 4 SDI and 2 HDMI input
- scaling output for SDI and HDMI PGM out
- HDMI and SDI Multiview output for monitoring
- CUT/AUTO/T-BAR transition
- FADE/WIPE/MIX transition effects
- GPIO Tally, PIP and FTB

3. SPECIFICATION
Inputs Video Inputs 4×3G/HD/SD-SDI, 2×HDMI
SDI Input Format 1080p 60/59.94/50/30/29.97/25/24/23.98
1080psF 30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50/30/29.97/25/24/23.98
625i 50 PAL, 525i 59.94 NTSC
HDMI Input Format 1080p 60/59.94/50/30/29.97/25/24/23.98/23.976
1080i 50/59.94/60
720p 60/59.94/50/30/29.97/25/24/23.98
576i 50, 576p 50
SDI Video Rate Auto detection, SD/HD/3G-SDI
SDI Compliance SMPTE 259M/ SMPTE 292M/ SMPTE 424M
Color Space and Precision SDI: YUV 4:2:2, 10-bit;
HDMI: RGB 444 8/10/12bit; YUV 444 8/10/12bit;
YUV 422 8/10/12bit
Outputs PGM Outputs 2×3G/HD/SD-SDI; 1×HDMI Type A
PGM Output Format 1080p 60/50/30/25/24; 1080i 50/60
Multiview Output 1×3G-SDI; 1×HDMI Type A
Multiview Output Format 1080p 60
Audio Audio Input 1×3.5mm Stereo audio; 1×RCA(L/R)
Audio Output 1×3.5mm Stereo audio; 1×RCA(L/R)
Others GPIO Tally
LAN RJ45
Power DC 12V, 1.8A
Consumption = 22W
Operation Temperature -20?~60?
Storage Temperature -30?~70?
Operation Humidity 20%~70%RH
Dimension 330×243.5×67mm
Weight 1kg
Warranty 2 Year Limited
Accessories Accessories 1×Power Supply (DC12V 2A)
