Intel NUC 11th Beast Canyon NUC11BTMi7 Core i7-11700B Processor 4.8GHz UHD Graphics Mini Business Gaming PC Desktop Thunderbolt 4 WiFi 6E Bluetooth 5.2 Barebone US Power Cord included
- Intel® CoreTM i7-11700B
- Intel® UHD Graphics
- 8 Core 16 Threads 24M Cache, up to 4.80 GHz
- Intel® Ethernet Controller i225-LM
- Intel® Wi-Fi 6E AX210(Gig+)
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Product Collection: Intel NUC Kit with 11th Generation Intel Core Processors
Code Name: Products formerly Beast Canyon
Supported Operating Systems: Windows 10, 64-bit*
Board Number: NUC11DBBi7
Internal Drives Supported: 4
TDP: 65 W
Board Chipset: Intel WM590 Chipset
Processor Included: Intel Core i7-11700B Processor (24M Cache, up to 4.80 GHz)
Total Cores: 8
Total Threads: 16
Processor Base Frequency: 3.20 GHz
Max Turbo Frequency: 4.80 GHz
Memory & Storage
Max Memory Size (dependent on memory type): 64 GB
Memory Types:
DDR4 3200MHz 1.2V SO-DIMM
DDR4 3200 MHz 1.35V SO-DIMM - XMP is required to enable 1.35V memory
Max of Memory Channels: 2
Max Memory Bandwidth: 51.2 GB/s
Max of DIM
Ms: 2
Processor Graphics
Integrated Graphics: Yes
Graphics Output: 2x Thunderbolt 4, HDMI 2.0 b
Displays Supported: 3
Expansion Options
PCI Express Configurations:
2x M. 2 PCIe X4 Gen3 slots (PCH), 2x M. 2 PCIe X4 Gen4 slots (CPU); Double-wide PCIe X16 Gen4 (CPU) slot, PCIe X4 Gen4 (CPU) slot, 12" max card length
Removable Memory Card Slot: SDXC with UHS-II support
M. 2
Card Slot (wireless): Intel Wi-Fi 6E AX210
M. 2
Card Slot (storage): 2x via PCH + 2x via CPU (NVMe)
I/O
USB Configuration:
6x rear USB 3.1 g2, 2x Thunderbolt 4 (USB 3.1 g2), 2x front USB 3.1 g2, 2x USB 3.1 via internal headers, 2x USB 2.0 via internal headers
SATA Ports: 2
RAID Configuration: 2x M. 2 SATA/PCIe SSD (RAID-0 RAID-1)
Audio (back channel + front channel): 7.1 digital; L+R+mic (F)
Integrated LAN: Intel Ethernet Controller i225-LM
Integrated Wireless: Intel Wi-Fi 6E AX210(Gig+)
Integrated Bluetooth: Yes
Additional Headers: 2x USB 2.0, FRONT_PANEL
Thunderbolt Ports: 2x Thunderbolt 4
Chassis Dimensions
357 x 189 x 120mm (8L)
Code Name: Products formerly Beast Canyon
Supported Operating Systems: Windows 10, 64-bit*
Board Number: NUC11DBBi7
Internal Drives Supported: 4
TDP: 65 W
Board Chipset: Intel WM590 Chipset
Processor Included: Intel Core i7-11700B Processor (24M Cache, up to 4.80 GHz)
Total Cores: 8
Total Threads: 16
Processor Base Frequency: 3.20 GHz
Max Turbo Frequency: 4.80 GHz
Memory & Storage
Max Memory Size (dependent on memory type): 64 GB
Memory Types:
DDR4 3200MHz 1.2V SO-DIMM
DDR4 3200 MHz 1.35V SO-DIMM - XMP is required to enable 1.35V memory
Max of Memory Channels: 2
Max Memory Bandwidth: 51.2 GB/s
Max of DIM
Ms: 2
Processor Graphics
Integrated Graphics: Yes
Graphics Output: 2x Thunderbolt 4, HDMI 2.0 b
Displays Supported: 3
Expansion Options
PCI Express Configurations:
2x M. 2 PCIe X4 Gen3 slots (PCH), 2x M. 2 PCIe X4 Gen4 slots (CPU); Double-wide PCIe X16 Gen4 (CPU) slot, PCIe X4 Gen4 (CPU) slot, 12" max card length
Removable Memory Card Slot: SDXC with UHS-II support
M. 2
Card Slot (wireless): Intel Wi-Fi 6E AX210
M. 2
Card Slot (storage): 2x via PCH + 2x via CPU (NVMe)
I/O
Specifications
USB Configuration:
6x rear USB 3.1 g2, 2x Thunderbolt 4 (USB 3.1 g2), 2x front USB 3.1 g2, 2x USB 3.1 via internal headers, 2x USB 2.0 via internal headers
SATA Ports: 2
RAID Configuration: 2x M. 2 SATA/PCIe SSD (RAID-0 RAID-1)
Audio (back channel + front channel): 7.1 digital; L+R+mic (F)
Integrated LAN: Intel Ethernet Controller i225-LM
Integrated Wireless: Intel Wi-Fi 6E AX210(Gig+)
Integrated Bluetooth: Yes
Additional Headers: 2x USB 2.0, FRONT_PANEL
Thunderbolt Ports: 2x Thunderbolt 4
Chassis Dimensions
357 x 189 x 120mm (8L)
