BIOSTAR TA970XE AM3+ AMD 970 + SB950 USB 3.0 ATX AMD Motherboard with UEFI BIOS
OPEN BOX Product Type
- AMD 970 + SB950
- FX / Phenom II / Athlon II / Sempron 100 Series
- DDR3 2000(OC)/1866/1600/1333/1066/800
Specs
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Biostar TA970XE
| Brand | BIOSTAR |
|---|---|
| Model | TA970XE |
| CPU Socket Type | AM3+ |
|---|---|
| CPU Type | FX / Phenom II / Athlon II / Sempron 100 Series |
| FSB | 2600 MHz |
| Chipset | AMD 970 + SB950 |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 2000(OC)/1866/1600/1333/1066/800 |
| Maximum Memory Supported | 32GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 2 (x16, x4) |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| Serial ATA (SATA) | 5 x SATA 6Gb/s |
|---|---|
| SATA RAID | 0/1/5/10 |
| Onboard Video Chipset | None |
|---|
| Audio Chipset | Realtek ALC892 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Realtek 8111E |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x Optical S/PDIF Out / 1 x PS/2 / 1 x S/PDIF Coaxial Out / 2 x USB 3.1 Gen 1 / 6 x Audio Jacks / 6 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 6 x USB 2.0 |
| IEEE 1394 | 1 x IEEE 1394a |
| eSATA | 1 x eSATA |
| S/PDIF Out | 1 x Optical, 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|---|
| Other Connectors | 1 x Printer Header 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12" x 8.86" |
| Power Pin | 24 Pin |
| Features | Supported Socket AM3+ processors AMD FX/ Phenom II/ Athlon II processor Supported AMD Mutil Core(x8,x6) AMD 140W processor support AMD 970 Chipset 4 DIMM supported DDR3-2000(OC)/1866/1600/1333/1066 Supported SATA 6Gb/s 2X speed than current SATA 3G Supported USB 3.0 BIOSTAR G.P.U ( Green Power Utility ) for green power saving your desktop AMD OverDrive with ACC feature (Advanced Clock Calibration) supported |
|---|
| First Listed on Newegg | May 01, 2012 |
|---|
