BIOSTAR TH55B HD LGA 1156 Intel H55 HDMI Micro ATX Intel Motherboard
- Intel H55
- Core i3 / Core i5 / Core i7 / Intel Core 1st Gen (LGA 1156) / Pentium
- DDR3 800/1066/1333/1600(OC)/1800(OC)/2000(OC)
Specs
Reviews (62)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Biostar TH55B HD
| Brand | BIOSTAR |
|---|---|
| Model | TH55B HD |
| CPU Socket Type | LGA 1156 |
|---|---|
| CPU Type | Core i3 / Core i5 / Core i7 / Intel Core 1st Gen (LGA 1156) / Pentium |
| Chipset | Intel H55 |
|---|
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 800/1066/1333/1600(OC)/1800(OC)/2000(OC) |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| Audio Chipset | Realtek ALC662 |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Realtek 8111DL |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x HDMI / 1 x PS/2 / 4 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 |
| Video Ports | D-Sub + DVI |
| HDMI | 1 x HDMI |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.6" x 9.6" |
| Power Pin | 24 Pin |
| Features | 5 Phases Power Design Integrated HDMI/DVI interface with HDCP Supporting all HD formats including720P,1080i, 1080P. ( Required processors with Intel HD Graphics) CPU integrated Graphics performance tunable via BIOS BIOSTAR G.P.U (Green Power Utility) Technology for Energy Saving BIOSTAR Toverclocker utility Optimized to deliver full windows 7 Experience |
|---|
| First Listed on Newegg | January 18, 2010 |
|---|
