Question 1

What are the dimensions?

Accepted Answer

Height without feet = 5 5/16"
Height with rubber feet = 5 9/16"
Width = 13 13/16"
Depth = 15 5/8" ( of course extra room needed for plugs cables and such)

Question 2

What power supply fits this thing? I've bought 2 "mATX" power supplies and neither fit this case

Accepted Answer

I bought the Apollo 470 Micro SFX 470 watt power supply for this case.. It works great and gives 470 watts, installed fine, and runs it just fine.  I needed something to run a nicer video card.  I have this setup with a AMD A-10 6800 quad core setup (4x4.1 ghz) and 16 gigs of memory and I am running a AMD 6670 video card with it running Dual Video with the onboard 6670 graphics.  I am using it as a HTPC and Media server and works perfect.  All parts purchased from Newegg BTW..

Question 3

The HDD LED, Reset SW, and the Power SW wires that come with this case, is the colored cable positive or negative?

Accepted Answer

Sorry, I can't remember how which is which but the polarity shouldn't matter on the power and reset switches, either way should work.  For the HDD LED I always put the colored wire on positive, if after the build the HDD LED isn't working just simply reverse it, you won't do any damage by having it backwards (it just won't light).

Sorry I'm not more help.

Question 4

could someone tell me if this case has good airflow for regular parts i want to put a R7 260X and FX-8320 in here but i don't know how well it would work?

Accepted Answer

I used a AMD A6-5400K Trinity cpu in it (the one with the on board video card)

And I had to add 2 more fans to the case(had to use bread ties to clip the fans in place tho as the case did not have a place for me to put them) . I would not use it with a Fx chip cpu build as they run too hot, my other pc has a FX-8120 in it but I have that in a full tower with 12 case fans..(course it also has a HD 6950 card which also runs hot)

This case is mainly for HTPC use as its fairly cramped inside...

that said I use it to run all my tv needs, XBMC, video served from my other main pc (the FX one) and it works fine.

Brand	DIYPC
Model	HTPC-KT28B

Type	Micro ATX Media Center / HTPC Case
Color	Black
Case Material	Acrylic / Steel
Power Supply	No
Motherboard Compatibility	Micro ATX
Side Window	No

Front USB Ports	USB 2.0 x 1; USB 3.0 x 1
Front FireWire Ports	No
Front Audio Ports	Yes
Front eSATA Ports	No
Front Card Reader	No
Remote Control Module	No
Front Display	No

Height	5.4"
Width	14"
Depth	15.2"
Weight	7.5 lbs.

DIYPC Black Acrylic / Steel HTPC-KT28B Micro ATX Media Center / HTPC Case

Learn more about the DIYPC HTPC-KT28B

Customer Reviews of the DIYPC HTPC-KT28B

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

External 5.25" Drive Bays	1
Internal 3.5" Drive Bays	2
Expansion Slots	4

Item#: N82E16811353017
