Blackmagic Design Dual Monitors SmartScope Duo 4K (HDL-SMTWSCOPEDUO4K2)
- 4:2:2 and 4:4:4
- Television sample rate of 48 KHz
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Blackmagic Design Pty. Ltd. SmartScope Duo 4K (HDL-SMTWSCOPEDUO4K2)
| Brand | Blackmagic Design |
|---|---|
| Model | SmartScope Duo 4K (HDL-SMTWSCOPEDUO4K2) |
| Format | SD Format Support: 525i29.97 NTSC, 625i25 PAL HD Format Support: 720p50, 59.94, 60 1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60 1080PsF23.98, 24, 25, 29.97, 30 1080i50, 59.94, 60 2K Format Support: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF Ultra HD Format Support: 2160p23.98, 24, 25, 29.97, 30 |
|---|---|
| Video Sampling | 4:2:2 and 4:4:4 |
| Audio Sampling | Television sample rate of 48 KHz |
| Color | Color Precision: 8-bit Color Space: YUV and RGB Colorspace Conversion: Hardware based real time |
| SDI | SDI Video Input: Automatically switches between SD, HD and 6G-SDI. Reclocked loop through output. SDI Video Output: 1 x 10-bit loop through SD, HD and 6G-SDI switchable. SDI Audio Input: 16 channels embedded in SD, HD and UHD. SDI Audio Output: 16 channels embedded in SD, HD and UHD. |
|---|---|
| USB Port | USB 2.0 for software updates and Ethernet for configuration |
| Software | Software Included: Configuration utility for MAC and Windows Internal Software Upgrade: Via included firmware updater software Physical Installation: 3RU |
|---|
| System Requirements | Operating Systems: macOS 10.12 Sierra, macOS High Sierra 10.13 or later. Windows 8.1 or Windows 10. |
|---|
| Power Consumption | < 20 Watts |
|---|---|
| Power Supply | 12V universal power supply included with international socket adapters for all countries. |
| Feature | SmartScope Duo 4K looks like a SmartView Duo but adds independent waveform monitoring so you can select between waveform, vectorscope, RGB parade, YUV parade, histogram and audio phase level displays. Each monitor is independent so can display any combination of scope or picture view! |
|---|
| Dimensions | 5.24" x 19.00" x 1.26" |
|---|---|
| Weight | 3.37 lbs. |
| First Listed on Newegg | February 22, 2018 |
|---|
