Blackmagic Design ATEM 2 M/E Broadcast Panel SWPANEL2ME

This item is covered under the Manufacturer Only Return Policy.

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Blackmagic Design Pty. Ltd. SWPANEL2ME

General
Brand	Blackmagic Design
Model	SWPANEL2ME

Performance
Button	Tri-color LED crosspoint buttons (20 direct crosspoints; 40 shifted crosspoints) with high-contrast RGB bitmap labels LCD bitmap buttons for menu control Next transition selectors: BKG, Key1 - Key2 (per M/E) DSK transition selectors: Auto, Cut, Tie/Pvw
Joystick	3-axis joystick, numeric keypad, 2x fader bars

Connection
Network Interface	2 x 10/100/1000 BaseT with loop output for additional control panels or computers
USB Port	1 x USB for firmware updates
Other Connector	10/100/1000 BaseT with loop output for additional control panels or computers 1 x USB for firmware updates

Compatibility
System Requirements	Mac OS X 10.7 Lion or later, and Mac OS X 10.8 Mountain Lion or later. Aerospace Certified Embedded OS. Windows 7 64-bit or Windows 8 32-bit or 64-bit. Aerospace Certified Embedded OS.

Power
Power Consumption	75W

Specification
Specification	Crosspoint Button Type: Tri-Color LED. Preview Transition: Yes Transition Rate Displays: Yes

Feature
Feature	The Blackmagic Design ATEM 2 M/E Broadcast Panel is a perfect companion to a professional live switcher, such as Blackmagic Design's ATEM 2 M/E Production Switcher (not included). With a broad field populated by high-quality buttons, knobs, T-bars, and a 3-axis joystick, you'll be able to customize your panel's operation to your exact needs and preferences - without compromise. Complex, multi-layer productions deserve a versatile panel, and the ATEM 2 M/E certainly fits the bill for live broadcast events. All controls are at your fingertips, so you can instantly command the switcher to switch cameras and execute transitions, fades, DVE effects, and more. This 37" wide panel gives you plenty of elbow room in which to operate. The ATEM 2 M/E Broadcast Panel connects to a switcher via 10/100/1000 BaseT Ethernet, and there's loop-through Ethernet for connecting to another panel or to a media-management computer. The panel receives firmware updates via its USB input. Tri-color LED crosspoint buttons - 20 direct crosspoints and 40 shifted crosspoints High-contrast RGB bitmap crosspoint labels LCD bitmap buttons for menu control On-air indicator

Dimension
Dimensions	37.27" X 14.14" X 4.8"
Weight	33.6 lbs.

Additional Information
First Listed on Newegg	April 12, 2013
