BoxCast BoxCaster HDSD2 (BXC-HDSD2) HD Live Video Streaming Encoder
- Stream with the BoxCast Platform
- Broadcast to Multiple Destinations
- Stream in High Definition
- Automate Your Live Stream
- Bring in External Audio
- Wired or Wireless Internet
- Control from Dashboard or Broadcaster App
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the BoxCast BoxCaster HDSD2 (BXC-HDSD2)
| Brand | BoxCast |
|---|---|
| Model | BoxCaster HDSD2 (BXC-HDSD2) |
| Type | Digital Media Streamer |
|---|---|
| Specifications | BACKHAUL PROTOCOLS: BoxCast Flow: backhaul protocol providing adaptive recovery, content-aware forward error correction, encryption, link quality adjustment, and TCP/UDP diversity. SUPPORTED INPUT RESOLUTIONS: 480p 29.97/30/59.94/60 525p 60 576p 25/50 720p 25/29.97/30/50/59.94/60 1080i 50/59.94/60 1080p 25/29.97/30/50/59.94/60 STREAMING RESOLUTIONS: Up to 720p30 inputs encode at same resolution 720p60 input encodes 720p at 30fps 1080p60 input encodes 720p at 30fps 1080p30 input encodes 1080p at 27fps 1080i60 input encodes 1080p at 23fps STREAMING DESTINATIONS: BoxCast Platform, including native players for web, mobile, AppleTV, and Roku Facebook Live YouTube Periscope Twitch Other RTMP Destinations NETWORK: IP address assignment via DHCP Automatic Firmware Updates MINIMUM UPLOAD SPEED TO STREAM: 480p30 - 1.5 mbps 720p30 - 3 mbps 1080p30 - 6 mbps POWER: 12V DC Power Supply Included 5W to 10W nominal power consumption with USB accessories DIMENSIONS: 4.34"W x 3.06"D x 0.94"H WEIGHT: Weight: 0.50 lb. BODY: Rugged, plastic casing Slip-free, Dampening Rubber Feet CLIMATE: Temperature: 0 to +70 C Humidity: 0% to 90% non condensing CONTROL: Simple, 3 Light, No Button Interface Schedule & Setup Broadcasts from Responsive, web-based Dashboard or Broadcaster App for iOS Automated Start/Stop Scheduling |
| Video Encoding | H.264 high profile level 4.2 |
|---|
| Interface | 10/100BASE-T port 802.11 a/g/n Wi-fi with Beam Forming MIMO |
|---|---|
| Audio | AUDIO ENCODING: AAC-LC audio compression |
| Ports In | VIDEO INPUT: 1 x HDMI HD Video Input (480i to 1080p60) 1 x Composite SD Video Input (NTSC/PAL) AUDIO INPUT: Embedded Audio Input 2 x RCA Stereo Line In Audio Input (48 kHz) USB Input for BoxCast Wireless Scoreboard Adapters |
| Features | Stream with the BoxCast Platform The BoxCaster works seamlessly & exclusively with BoxCast's reliable, scalable streaming platform. BoxCast is the only streaming company that has built its entire infrastructure from beginning to end, giving you unprecedented levels of compatibility. The BoxCast Platform offers acquisition, compression, cloud transcoding, archiving, video on demand, pay-per-view settings, and a scalable delivery infrastructure. BoxCast offers various plans to fit the needs of your organization: Live, Standard, Advanced, Advanced Plus. Broadcast to Multiple Destinations Simultaneously broadcast to your website, Facebook Live, YouTube and other RTMP destinations. The BoxCaster streams with minimal required bandwidth to the BoxCast Platform, which then streams to all desired destinations. Stream in High Definition The BoxCaster will accept video in up to 1080p/60fps via HDMI and stream up to 1080p/27fps. Automate Your Live Stream The BoxCaster starts automatically at the time you schedule it to, ensuring you never have to push a button to go live. Bring in External Audio Bring an audio feed from your sound board or other sources into your broadcast with the RCA Stereo Line In audio inputs. Wired or Wireless Internet Connect the BoxCaster to the internet with either a wired or wireless connection. Note: A wired internet connection is always recommended. Control from Dashboard or Broadcaster App Schedule, setup and manage all of your broadcasts from the web-based, responsive BoxCast Dashboard or BoxCast's Broadcaster App for iOS. Portable Size The BoxCaster's compact size allows it to travel with you wherever you are streaming. Streaming Plan Activation Upon purchase of a BoxCaster and a BoxCast Streaming Plan, an activation code will be emailed to you. Follow the instructions in the email to create your BoxCast account and start streaming. |
|---|
| First Listed on Newegg | January 09, 2018 |
|---|
