    Intel BOXDP55SB LGA 1156 Intel P55 Micro ATX Intel Motherboard

    (26) Write a Review
    • Intel P55
    • Core i3 / Core i5 / Core i7 / Intel Core 1st Gen (LGA 1156) / Pentium
    • DDR3 1600/1333/1066 XMP Supports overclocking beyond 1333 MHz
    🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
    +
    +
    Specs
    Reviews (26)
    avatar

    Any questions? Our AI beta will help you find out quickly.

    Try me now

    Learn more about the Intel BOXDP55SB

    Model
    Brand Intel
    Model BOXDP55SB
    Supported CPU
    CPU Socket Type LGA 1156
    CPU Type Core i3 / Core i5 / Core i7 / Intel Core 1st Gen (LGA 1156) / Pentium
    Chipsets
    Chipset Intel P55
    Onboard Video
    Onboard Video Chipset None
    Memory
    Number of Memory Slots 4x240pin
    Memory Standard DDR3 1600/1333/1066
    XMP Supports overclocking beyond 1333 MHz
    Maximum Memory Supported 16GB
    Channel Supported Dual Channel
    Expansion Slots
    PCI Express 2.0 x16 1 x PCI Express 2.0 x16
    PCI Express x8 1 x PCI Express x8
    PCI Express x1 2 x PCI Express x1
    Storage Devices
    SATA RAID 0/1/5/10 Matrix RAID
    Onboard Audio
    Audio Chipset Realtek ALC889
    Audio Channels 10-channel (7.1+ 2 independent multi-streaming)
    Onboard LAN
    LAN Chipset Intel PRO 82578DC
    Max LAN Speed 1Gbps
    Bluetooth Yes
    Rear Panel Ports
    USB 1.1/2.0 8 x USB 2.0
    IEEE 1394 1 x IEEE 1394a
    eSATA 1 x eSATA 3Gb/s
    S/PDIF Out 1 x Optical
    S/PDIF In 1 x Optical
    Audio Ports 6 Ports
    Internal I/O Connectors
    Onboard USB 5 x USB 2.0 (1 on board, 4 via internal headers)
    Onboard 1394 1 x 1394a
    Physical Spec
    Form Factor Micro ATX
    Dimensions (W x L) 9.6" x 9.6"
    Power Pin 24 Pin
    Features
    Features Intel Turbo Boost Technology

    Dolby Home Theater (Dolby Pro Logic II, Dolby Virtual Speaker, Dolby Digital Live, Dolby Headphones)

    Bluetooth Connectivity

    Windows Vista Premium WHQL certified

    Consumer Infrared receiver and emitter (Vista MCE compliant)

    Back to BIOS switch

    On Board LED post decoder
    Additional Information
    First Listed on Newegg December 28, 2023
